- Eén universeel product voor de civiele ploeg, onafhankelijk van de gekozen 'direct buried' klantaansluitkabel of buis.
- Standaard detectiespoel in het deksel (Telecom 101,4 kHz).
- Eenvoudige montage.
- Zanddichte poortafdichtingen.
- Onderdelen in gebruiksvolgorde verpakt in een stevige kartonnen omdoos.
- Montage-instructies bijverpakt.
- Afmetingen: 90 x 35 x 30 cm (LxBxH), gronddekking 30 cm bij leidingen op 60 cm diepte.
- Scope of delivery: distribution closure, sand seal
Supply sleeve (distribution point, underground) consisting of 3 parts, base plate, housing body and housing cover. Has a slot for the splice distributor housing (FMP). The supply sleeve can be used in combination with the splice distributor housing as a distribution point in the FTTH street distribution network. The splice distribution housing (FMP) is mounted in the housing cover. The splice distribution housing (FMP) with sealing ring in the housing cover complies with protection class IP68. The immersion bell principle protects the splice connection against external influences. The housing cover locks onto the housing body with 2x slide locks. The detection coil (frequency 101.4 kHz) installed in the housing cover enables subsequent location. The supply sleeve complies with standard EN 124-1:2015 Group 2. Compliance with a minimum ground cover of 300 mm and a maximum installation depth of 1,800 mm is mandatory. Fibre optic cables and pipe systems are accommodated via 4x slots (2x slots on each side). The foam seal for the inlet/outlet is included in the scope of delivery. The excess length of up to 6,000 mm for fibre optic cables and pipe systems is stored in the housing body (storage in loops) .
Dimensions: 900 x 350 x 300 mm (LxWxH)
Weight: 10,000 g
Colour: Black/grey
Scope of delivery: Supply sleeve, 4x sand seal
Installation type: Underground
Protection class: IP68
Excess length management: 6,000 mm
Chemical resistance: Yes
Vibration resistance: Yes
Impact resistance: IK07
Halogen-free: Yes
Number of cable/conduit entries: 4
Cable/conduit entry properties: Sand-tight
Cable/conduit entry bending resistance: Yes
Cable/conduit entry Ø: 38x 7.0 mm, 2x 14/10 mm
Housing closure: Lock
Location: 101.4 kHz detection coil in the cover
Standard: EN 124-1:2015 Group 2
Ground cover (min.): 300 mm
Installation depth (max.): 1,800 mm
Storage temperature range: -10 °C / +60 °C
Installation temperature range: -10 °C / +60 °C
Operating temperature range: -20 °C / +60 °C
