• Compacte afmetingen: Ø 85 mm x 155 mm
• IP68 waterdicht, conform EN 60529
• Geschikt voor kabeldiameters Ø 5 mm - Ø 6,5 mm
• Geïntegreerde trekontlasting per kabel
• Cassette is geschikt voor glasvezel met R = 22,5 mm
• De splice tray capaciteit bedraagt 2 splice connectors ANT/mini heatshrink of 2 splice protectors heatshrink Ø 2,4 mm x 45 mm.
• Per stuk verpakt in transparante folie
• Scope of delivery: repair sleeve

Repair sleeve is used to achieve extension or repair of fibre optic connection or customer cables. Complies with protection class IP68. Sealing and closure are achieved by means of a twist lock. For use underground and above ground in combination with surface-mounted mounting bracket (AT29027). Entry and exit with integrated strain relief for fibre optic cables with a diameter of 5.0 to 6.5 mm. Has a slot for up to 2x fibre optics and splices distributed across 1x splice cassette. Splice protection holder is designed for ANT crimp splice protection, mini heat-shrink tubing and HS heat-shrink tubing.
Dimensions: 155 x 85 mm (LxW)
Weight: 165 g
Colour: Black/grey
Scope of delivery: Repair sleeve
Installation type: Underground
Above ground (surface-mounted bracket)
Protection class: IP68
Chemical resistance: Yes
Vibration resistance: Yes
Impact resistance: IK09
Halogen-free: Yes
Design: Cable
Number of fibres: 2
Loop length: 230 mm (splice cassette)
Bending radius: R = 22.5 mm (splice cassette)
Splice protection holder: ANT crimp / mini heat-shrink tubing, heat-shrink tubing
Cable/conduit entry number: 2
Cable/conduit entry properties: Sand/waterproof
Cable/conduit entry bend resistance: Yes
Cable/conduit entry Ø: 5.0 – 6.5 mm
Housing closure: twist lock
Standard: EN 124-1:2015 Group 2
Storage temperature range: -10 °C / +50 °C
Installation temperature range: -10 °C / +50 °C
Operating temperature range: -20 °C / +60 °C
