• Scope of delivery: Compact Gf-GV, LC/APC QD coupling

Compact building distributor (Gf-GV) can also be used as a house transfer point (HÜP). Suitable for surface mounting. Compact building distributor complies with protection class IP55. Consisting of distributor housing, door, splice cassette and coupling bracket. Suitable for microduct slots, single-pull seals and fibre optic customer cables. 1x slot for microducts and fibre optic cables with a diameter of up to 11.0 mm and 2x outputs for up to 12x patch cables with a diameter of up to 2.0 mm. Equipped with 1x LC/APC quad coupling with dust and laser protection caps. The coupling is installed in the housing and provides access protection for the plug connector. The compact building distributor has a lockable door and can be detached from the housing if necessary. Storage for ANT crimp splice protection and mini heat-shrink tubing. Slot for up to 24x fibre optics and splices distributed across 1x splice cassette. Approved for funding projects by atene KOM .

Dimensions: 258 x 186 x 61 mm (LxWxH)
Weight: 1,000 g
Colour: Light grey
Scope of delivery: Compact building distributor including splice cassette,
LC/APC QD coupling
Installation type: Surface-mounted
Protection class: IP55
Number of fibres: 4
Number of splice cassettes: 1
Number of couplings: 1
Coupling type: LC/APC QD
atene KOM approved: Yes
Halogen-free: Yes
Loop length: 250 mm (splice cassette)
Bending radius: 23 mm (splice cassette)
Splice protection holder: ANT crimp / mini heat-shrink tubing
Cable/conduit input quantity: 1
Cable/conduit input Ø: 11.0 mm
Cable/conduit outlet number: 2
Cable/conduit outlet Ø: 12x 2.0 mm
Storage temperature range -10 °C / +60 °C
Installation temperature range -10 °C / +60 °C
Operating temperature range -20 °C / +60 °C
