Flush-mounting back boxes with glow wire test 850°

similar

Einlasskasten 2x2
Artikel-No. 9924.850
E-No 372111229
  • Compatible with Feller SNAPFIX®
  • Essential in timber construction
  • Electrically well-insulated, shock and pressure-resistant.
  • Flat bearing surface thanks to 4 support points
  • For device screws Ø 3 mm
  • Max. tightening torque 0.5 Nm

Flush-mounting back boxes with glow wire test 850°

The in-wall boxes without halogene are suitable for installations on combustible materials. The boxes are produced in white polyproplene and have successfully passed the glow wire test at 850°C according to EN 60695-2-11.
  • Essential in timber construction
  • Electrically well-insulated, shock and pressure-resistant.
  • Flat bearing surface thanks to 4 support points
  • Compatible with Feller SNAPFIX®

Dimensions / Form

Product length:
190 mm
Product width:
130 mm
Product depth:
70 mm

Connections / Entries

For conduit Ø:
20 mm, 25 mm

Assembly / Installation

Assembly type:
HW (drywall/lightweight construction)
Certificate
2.9 MB | 14/11/2024
Instruction

Protective caps for inlet boxes of types 99xx.850

to prevent voltage transfer

528.1 KB | 07/02/2024
Einlasskasten 2x2
Artikel-No. 9924.850
E-No 372111229
  • Compatible with Feller SNAPFIX®
  • Essential in timber construction
  • Electrically well-insulated, shock and pressure-resistant.
  • Flat bearing surface thanks to 4 support points
  • For device screws Ø 3 mm
  • Max. tightening torque 0.5 Nm
