Maximum flexibility for the AGRO box for formwork.
Bringing together conduits of different sizes.
The new flush-mounted formwork box for casting into concrete is primarily designed to bring together conduits of various sizes at electrical distribution points and along cable routes. A plastic screw-on cover and a wet-room cover made of anodised aluminium are available as accessories. Both covers are supplied with six metal screws. The metal screws for the wet-room cover are rust-resistant.
The front part can be nailed to the formwork before the conduits are installed
Short nails means less deformation when hammered in
The rear part can be snapped into place on the front part
Can be combined together to make a row of units of any length
Secure the front part to the formwork using the six pre-installed nails.
Click the box into place on the front part.
If necessary, several formwork boxes can be installed in a row, end to end, and the boxes can be connected to each other by opening the appropriate end entries (M40 to M63).
The required conduit entries can be opened using a step drill...
… or opened with a screwdriver and a hammer.
The end entries (M40 to M63) can be opened using a hole saw.
If numerous conduits of various sizes require insertion, four large openings can be created by removing their cover panels using a screwdriver and hammer.
After the formwork has been removed, the box’s front panel can also be removed using a hammer and screwdriver as required.
