Brandschutzdosen Quickbox® Maxi HWD 90
- for fire protection ceilings F30-F90 or EI30-EI90 - For F30 (EI30) non-insulated fire-protection ceilings - For F60 (EI60) fire-protection ceilings backed with mineral insulation materials in compliance with EN 13501 part 1 - for F90 (EI90) fire-protection ceilings with Rockwool/Termarock 100
Decken-Verbindungsdose HWD 30
Brandschutzdosen Quickbox® Maxi HWD 90
Leitungsschotts LS 90
Dosenschott System DS 90 / 74 mm
Deckenschott System DS 90 / 120 mm
Brandschutzgehäuse FlamoX®

Electrical installations in fire protection

Box, housing and sealing systems for fire-protection walls and ceilings.

The aim of constructional fire-protection measures is to prevent the spread of fire and smoke if a fire breaks out and to ensure that emergency and escape routes can still be used. In doing this, the focus is especially on the electrical installation, because it can have a major effect on the fireresistance of a fire protection wall or ceiling.

By using the AGRO fire protection systems, which activate automatically and maintain the fire resistance class in spite of the embedded electrical installation, the electrical trade can provide tested and certified fire protection from a single source. No more home-made encasings, filling work using fire-protection mortar or stuffing with mineral wool!
Safety in timber-frame construction Products for walls Cable routing Ceiling products
Safety in timber-frame construction
Products for walls
Cable routing
Ceiling products
chevron_left_FILL0_wght400_GRAD0_opsz24
chevron_right_FILL0_wght400_GRAD0_opsz24
Fire protection.
Brochure
Fire protection.

Box, housing and sealing systems for fire-protection walls and ceilings.

21.1 MB
Quickbox HWD 90
AGRO fire protection range - More safety in timber frame construction.
Flyer
AGRO fire protection range - More safety in timber frame construction.

The all-rounders for safe electrical installations, when fire protection is required.

797.7 KB
Quickbox HWD 90 Maxi

Fire protection technology. | Legal basis.

Due to federalism, fire protection legislation in Switzerland is the responsibility of the cantons. The cantons regulate fire protection in their fire protection, fire protection or fire police legislation, partly also in laws on building insurance. Due to the intercantonal agreement to dismantle technical barriers to trade (IVTH), the Swiss fire protection regulations VKF have been incorporated into cantonal legislation.



The cantonal fire police order structural or technical fire protection measures under given conditions. The concrete implementation and execution is the responsibility of the owner, who has been imposed the obligation. If the prescribed fire protection measures are not complied with, the owner can demand that the building be upgraded. Otherwise there is a risk of exclusions from the insurance benefits. The authorities do not have to bear the consequences of damage resulting from the failure to assume personal responsibility - the owner remains responsible.

Products for timber-frame construction

  • Greater safety in timber-frame construction.

    The all-rounders for safe electrical installations where fire protection is required.
    VKF certification for installation in timber stud walls. The entire range is now also approved for installation in timber stud walls. HWD 90 cavity wall boxes for EI30–EI90 fire protection walls ensure certified and fire-safe electrical installation. The intelligent AFS technology reacts immediately to fire and heat and automatically seals the installation opening. This preserves the wall’s fire resistance class and ensures the emergency route remains secure. Suitable for use in all fire protection walls and with a fire resistance duration of up to 90 minutes, it ensures maximum flexibility – even in the event of design changes. At the same time, it also maintains the wall’s sound insulation function.

    AGRO fire protection products can be installed easily, safely and cleanly. As the fire protection products can be fitted using standard tools – without any need for filling or smoothing – installation requires minimal effort – and no training is needed!

    • Compatible with Feller SNAPFIX®
    • For EI30–EI90 fire protection walls
    • For wall entry and feed-throughs
    • Maintains the wall’s sound insulation function
    • Retrofitting is also possible
    • Can be used as a junction box with a fire protection cover
    • Also suitable for installation directly opposing the previous installation
    • No need to use fire protection foam or sealant
    • Made from insulation-forming material
AGRO fire protection range - More safety in timber frame construction.
Flyer
AGRO fire protection range - More safety in timber frame construction.

The all-rounders for safe electrical installations, when fire protection is required.

797.7 KB
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
Quickbox® Maxi HWD 90 1x1
Artikel-No. 9499-77
E-No 372632509
See more
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF approval 21042 - also for opposing installation - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm
Quickbox® HWD 90 1x1
Artikel-No. 9498-77
E-No 155012029
See more
- for EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - attachment using tried-and-tested FX⁴ metal plate screws - with integrated sealing inserts - ensures smoke-tight room separation (seals against cold smoke) - unlimited building material shelf life
Box sealing system DS 90 / 120 mm
Artikel-No. 9459-04
E-No 121819018
See more
- for EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - for wall entry, wall outlet and penetration - without use of fire-protection foam or putty - made of intumescent material - automatic room separation of the installation opening - unlimited building material shelf life
Cable sealing system LS 90
Artikel-No. 9459-01
E-No 121814608
See more
- for EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - for wall entries and feed-throughs - without use of fire-protection foam or putty - made of intumescent material - automatic room separation of the installation opening - unlimited building material shelf life
Conduit sealing system RS 90
Artikel-No. 9459-02
E-No 121812608
See more
- for EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - for wall entries and feed-throughs - attachment using tried-and-tested FX⁴ metal plate screws - with integrated sealing inserts - ensures smoke-tight room separation (seals against cold smoke) - unlimited building material shelf life
Box sealing system DS 90 / 74 mm
Artikel-No. 9459-03
E-No 121819008
See more

Products for walls

  • Fire protection boxes Quickbox® Maxi HWD 90.

    For safe classes up to EI 90.
    Cavity wall socket HWD 90 for EI30-EI90 fire protection walls. The intelligent technology reacts to fire and heat immediately and automatically closes the installation openings. This means that the fire resistance class of the fire protection wall is guaranteed and escapes routes secured.

    The VKF approval proves the reliable quality of the AGRO Quick-box® HWD 90 fire protection boxes. All boxes of type HWD 90 have the complete sound insulation function up to a sound insulation value of 78 dB.
    • For fire protection walls EI 30 to EI 90
    • Also retrofit installation
    • Installation up to 3x2 combination
    • Also opposite installation
    • Maintains the sound insulation function of the wall
    • Can be used as connection box with fire protection lid
    • Identifiable as a fire protection box by the red colour of the box
    Show products
Quickbox HWD 90 Maxi
Quickbox HWD 90

Cable routing

  • Fire sealings.

    Feed-throughs and entries in cavities, masonry and concrete.
    ealings in fire protection walls are needed when cables or conduits must be fed through walls with a specific fire resistance class. In order to maintain the relevant rating, expert sealing of the opening is needed to prevent fire or smoke from spreading.

    AGRO solutions guarantee fast and above all absolutely safe and reliable sealing if a fire breaks out. There is no need at all for the time-consuming and messy use of fire protection putty, foam or mortar. Installation is as easy as fitting a AGRO cavity wall box.
    • Secure, visible, certified fire sealing
    • For wall feed-throughs and entries
    • No filling and smoothing
    • Automatic sealing of joints and gaps between cables
    • Non-destructive later fitting
    • For cable bundles or individual installation conduits
    • Also for mixed population of cable and conduit bundles

    The cable sealing LS 90 and the conduit sealing RS 90 can easily be fitted in a few simple steps. Use a suitable cutter or drill to make the installation opening and insert the flexible sealing. For retrofitting, open the sealing and push it over the existing cable or conduit. The cable and conduits sealings can be arranged as a group.
    Show product
Deckenschott System DS 90 / 74 mm und DS 90 / 120 mm
Sealed transits DS 90 / 74 mm and DS 90 / 120 mm for fire-protection ceilings.
Flyer
Sealed transits DS 90 / 74 mm and DS 90 / 120 mm for fire-protection ceilings.

Certifed systen for the sealed transition of cables and conduits through fire-protection ceilings. Leaflet available in German, French and Italian.

2.8 MB

Ceiling products

  • HWD 30 ceiling boxes

    For fire protection ceilings F30–F90.
    The HWD 30 ceiling box for reliable fire protection ensures fire resistance ratings from F30 to F90. In the event of a fire, the integrated fire-retardant coating intumesces immediately and seals the opening in the ceiling. The HWD 30 ceiling box also ensures safety during retrofitting.

    • For fire protection ceilings F30–F90 or EI30–EI90
    • No need for encasing
    • For the installation of smoke detectors, motion detectors, etc.
    • Can be used as a ceiling junction box with a fire protection cover
    • Retrofitting is also possible
    Show product

  • Fire-stop box FlamoX®.

    For luminaires and loudspeakers.
    The FlamoX® fire-protection housings form the new generation of the tried-and-tested housings for the installation of accessories such as luminaires, loudspeakers or other devices in suspended fire-protection ceilings. For this new generation of housings, the dimensions were matched to modern lighting systems, so it is ideal for universal use. Now it is possible to install LED luminaires, luminaires with compact fluorescent lamps, low-voltage and high-voltage halogen lamps, loudspeakers and other devices, including any necessary operating devices.

    The housings can easily be installed from below in fire-protection ceilings through the installation opening which is made for them.  Because of the low weight of the housings, even when luminaires or loudspeakers are fitted, the maximum permitted weight load of 5 kg/m² is not exceeded. This ensures that no additional suspension devices are needed.

    Flamox® housings correspond to fire-resistance class F30 (El30) and withstand fire loads from above and below. This means that electrical installation companies can ensure optimal building construction fire protection for fire-protection ceilings.
    Show products
Installation housing FlamoX®
Fire-stop box FlamoX®.
Flyer
Fire-stop box FlamoX®.

Certified fire-stop box for the installation of luminaires and loudspeakers into fire protection ceilings. Leaflet available in German, French and Italian.

1.5 MB
