Covers for flush-mounted junction boxes
Push-on cover with insulated centre screw, RAL 7012
accessories
Insulated round head screw, 3.5x80 mm
Artikel-No.
9901.37.80
E-No
163013180
- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
Insulated round head screw, 3.5x90 mm
Artikel-No.
9901.37.90
E-No
163013190
- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
Insulated round head screw, 3.5x100 mm
Artikel-No.
9901.37.100
E-No
163013200
- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
Insulated round head screw, 3.5x120 mm
Artikel-No.
9901.37.120
E-No
163013220
- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
similar
Push-on cover with insulated centre screw, RAL 9010
Artikel-No.
9909.22.37
E-No
155911028
- Conforms to EN 60670-1
- With two isolated and tested centre screws (L=40/70 mm)
- UV-resistant
Push-on cover with insulated centre screw, RAL 9005
Artikel-No.
9909.22.37.60
E-No
155910258
- Conforms to EN 60670-1
- With two isolated and tested centre screws (L=40/70 mm)
- UV-resistant
Push-on cover with insulated centre screw, RAL 7047
Artikel-No.
9909.22.37.65
E-No
155910238
- Conforms to EN 60670-1
- With two isolated and tested centre screws (L=40/70 mm)
- UV-resistant
Dimensions / Form
- Product length:
- 130 mm
- Product width:
- 130 mm
- Product depth:
- 7 mm
Assembly / Installation
- Assembly type:
- BB (solid construction)
Safety / Properties
- Special application:
- on-site mixed concrete
