Short entry thread metric
- Two-piece sealing insert - not overall length insulated - For high temperature applications
- Progress AgreenO EMV easyCONNECT - Two-piece sealing insert - not overall length insulated
1 / 2
Open Cadenas Modal
- Two-piece sealing insert - not overall length insulated - For high temperature applications
- Progress AgreenO EMV easyCONNECT - Two-piece sealing insert - not overall length insulated
  • Two-piece sealing insert
  • not overall length insulated
  • For high temperature applications
Read more Read less

Cable glands Progress® EMC easyCONNECT stainless steel A2 with contact spring

Unbekannt
Artikel-No.: 1083.20.96
EAN: 7611614477275
CE
UKCA
Thread: M20x1.5
Min. clamping range: 11 mm
Max. clamping range: 15 mm
Clamping range with inlet min.: 8 mm
Clamping range with inlet max.: 11 mm
Spanner size: 24 mm
Properties: For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables
Thread type: metric
Thread length: short
clamp technology: Compression technology
Contact: Contact spring
Protection class: IP68, IP69
Protection class with condition: IP 68 (10 bar) / IP69
Shielded design (EMC): Yes
Shipping: 50
More product details
Datasheet (PDF)

accessories

- Grounding straps suitable for cable glands - Entry thread Pg
Grounding straps suitable for cable glands
Artikel-No. 1020.80.10
E-No 121940508
  • Grounding straps suitable for cable glands
  • Entry thread metric
See more
Thread M12x1.5 M12x1.5 M16x1.5 M20x1.5 M25x1.5 M32x1.5 M40x1.5 M50x1.5 M63x1.5
Min. clamping range 3.5 mm 5 mm 8 mm 11 mm 16 mm 21 mm 28.5 mm 37 mm 46 mm
Max. clamping range 5 mm 6.5 mm 10.5 mm 15 mm 20.5 mm 25.5 mm 33 mm 42 mm 52 mm
Clamping range with inlet min. 6 mm 8 mm 12.5 mm 17 mm 24 mm 33 mm 40 mm
Clamping range with inlet max. 8 mm 11 mm 16 mm 21 mm 28.5 mm 37 mm 46 mm
Spanner size 17 mm 17 mm 19 mm 24 mm 30 mm 36 mm 46 mm 55 mm 70 mm
Properties For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables
Thread type metric metric metric metric metric metric metric metric metric
Thread length short short short short short short short short short
clamp technology Compression technology Compression technology Compression technology Compression technology Compression technology Compression technology Compression technology Compression technology Compression technology
Contact Contact spring Contact spring Contact spring Contact spring Contact spring Contact spring Contact spring Contact spring Contact spring
Protection class IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68 IP69, IP68
Protection class with condition IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69 IP 68 (10 bar) / IP69
Shielded design (EMC) Yes Yes Yes Yes Yes Yes Yes Yes Yes
Artikel-No. 1083.12.96.050 1083.12.96.065 1083.17.96 1083.20.96 1083.25.96 1083.32.96 1083.40.96 1083.50.96 1083.63.96
E-Number
Packaging / Shipping - / 50 - / 50 - / 50 - / 50 - / 25 - / 25 - / 10 - / 10 - / 5
Show product chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24
1 = One-piece sealing insert. Long entry thread metric

Progress® EMC easyCONNECT Multi

For shielded cables in limited space conditions, Progress® EMC easyConnect Multi is the perfect solution. Whether for cables of the same or different diameters, or for preassembled, non-preassembled or hybrid cables: The innovative contact spring facilitates problem-free earthing. The presented pictures show only a small selection of the many possibilities.
For shielded cables in limited space conditions, Progress® EMC easyConnect Multi is the perfect solution. Whether for cables of the same or different diameters, or for preassembled, non-preassembled or hybrid cables: The innovative contact spring facilitates problem-free earthing. The presented pictures show only a small selection of the many possibilities.
You specify the number of cable entries and the relevant diameters, and we will supply the EMC Multi cable gland to meet your needs.
You specify the number of cable entries and the relevant diameters, and we will supply the EMC Multi cable gland to meet your needs.
Available on request: Executions in steel A2 and A4 Entry thread Pg and NPT With FPM sealing inserts for high temperaturesWith sealing inserts of type F in accordance with EN 45545
Available on request: Executions in steel A2 and A4 Entry thread Pg and NPT With FPM sealing inserts for high temperaturesWith sealing inserts of type F in accordance with EN 45545

Dimensions / Form

Thread:
M20x1.5
Spanner size:
24 mm
Dimension H:
27 mm
Thread length L:
8 mm

Connections / Entries

Min. clamping range:
11 mm
Max. clamping range:
15 mm
Clamping range with inlet min.:
8 mm
Clamping range with inlet max.:
11 mm
clamp technology:
Compression technology
Contact:
Contact spring

Safety / Properties

Shielded design (EMC):
Yes

Features

Properties:
For a quick and safe installation of partially dismantled cables as well as thoroughly shielded cables
Thread type:
metric
Thread length:
short

Approvals / Certifications

Protection class:
IP68, IP69
Protection class with condition:
IP 68 (10 bar) / IP69

Storage / Installation / Operation

Minimum operating temperature:
-40 °C
Maximum operating temperature:
200 °C
Instruction

EMC cable gland Progress® EMC easyCONNECT.

AGRO cable glands for interference-free installations.

563.3 KB | 10/09/2019
Download
Instruction

Assembly torques

1 MB | 30/03/2022
Progress® EMC easyCONNECT stainless steel A2
Flyer

Progress® EMC easyCONNECT stainless steel A2

Quick, safe and convenient installation thanks to an innovative contact spring.

2.1 MB
