Maximum installation flexibility thanks to maximum clamping range
1 /
2
Cable glands Progress® multiLAYER nickel-plated brass
Thread:
M20x1.5
Min. clamping range:
4 mm
Max. clamping range:
15 mm
Spanner size:
24 mm
Thread type:
metric
Thread length:
long
clamp technology:
Compression technology
Protection class:
IP68, IP69
Protection class with condition:
IP 68 (10 bar) / IP69
Shipping:
50
Dimensions / Form
- Thread:
- M20x1.5
- Spanner size:
- 24 mm
- Dimension H:
- 23 mm
- Thread length L:
- 10 mm
Connections / Entries
- Min. clamping range:
- 4 mm
- Max. clamping range:
- 15 mm
- clamp technology:
- Compression technology
Features
- Thread type:
- metric
- Thread length:
- long
Approvals / Certifications
- Protection class:
- IP68, IP69
- Protection class with condition:
- IP 68 (10 bar) / IP69
Storage / Installation / Operation
- Minimum operating temperature:
- -50 °C
- Maximum operating temperature:
- 105 °C
