Long entry thread metric
1 /
2
Hydraulic hose adapter Progress® brass
Thread:
M25x1.5
Min. clamping range:
4 mm
Max. clamping range:
14.5 mm
Spanner size:
24/30 mm
Protection class:
IP68, IP69
Protection class with condition:
IP 68 (10 bar) / IP69
Shipping:
25
Dimensions / Form
- Thread:
- M25x1.5
- Spanner size:
- 24/30 mm
- Dimension H:
- 40 mm
- Thread length L:
- 15 mm
Connections / Entries
- Min. clamping range:
- 4 mm
- Max. clamping range:
- 14.5 mm
Approvals / Certifications
- Protection class:
- IP68, IP69
- Protection class with condition:
- IP 68 (10 bar) / IP69
Storage / Installation / Operation
- Minimum operating temperature:
- -50 °C
- Maximum operating temperature:
- 105 °C
