Ceiling junction box
- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx - Max. suspension load 50 N (5 kg)
Open Cadenas Modal
  • Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
  • Max. suspension load 50 N (5 kg)
Read more Read less

Lamp box with perforated collar Ø 96 mm

AGRO AG
Artikel-No.: 9954.10
E-No: 165921028
EAN: 7611614025940
SZ
CE
Product Ø: 96 mm
Product depth: 81 mm
Number of entries: 4
For conduit Ø: 20 mm, 25 mm
Shipping: 25
More product details
Datasheet (PDF)

accessories

- With central plug-in connector - For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit - Screw not included
Cover
Artikel-No. 11081
E-No 165950308
  • With central plug-in connector
  • For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
  • Screw not included
See more
- With central plug-in connector - For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit - Screw not included
Cover with cable entry
Artikel-No. 11082
E-No 165950408
  • With central plug-in connector
  • For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
  • Screw not included
See more
- With central plug-in connector - For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit - Screw not included
Cover
Artikel-No. 11088
E-No 165950608
  • With central plug-in connector
  • For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
  • Screw not included
See more
- UV-resistant
Cover 88x88 mm
Artikel-No. 9919.10
E-No 374161008
  • UV-resistant
See more
- UV-resistant
Cover
Artikel-No. 11086
E-No 165950508
  • UV-resistant
See more
- Can also be used as cover for reserve conduit exits - Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting) - For Art.-No. 1245-60/-62/-63 and 1246-57
Screwed-on cover
Artikel-No. 10100
E-No 165950008
  • Can also be used as cover for reserve conduit exits
  • Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting)
  • For Art.-No. 1245-60/-62/-63 and 1246-57
See more
- For retrofitting in ceiling boxes (EN 60670) - With self-forming thread, insulated - Proof voltage: 2500 V tested - Suspension load max. 5 kg
Insulated hook screw, 40 mm
Artikel-No. 1225-40
E-No 163612040
  • For retrofitting in ceiling boxes (EN 60670)
  • With self-forming thread, insulated
  • Proof voltage: 2500 V tested
  • Suspension load max. 5 kg
See more
- For retrofitting in ceiling boxes (EN 60670) - With self-forming thread, insulated - Proof voltage: 2500 V tested
Insulated round head screw, 3.5x50 mm
Artikel-No. 9901.37.50
E-No 163013150
  • For retrofitting in ceiling boxes (EN 60670)
  • With self-forming thread, insulated
  • Proof voltage: 2500 V tested
See more
Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab
Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab
Artikel-No. 9959.68
E-No 165920008
See more

similar

- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx - Max. suspension load 50 N (5 kg)
Lamp box, outlet Ø 45 mm
Artikel-No. 9952
E-No 165920128
  • Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
  • Max. suspension load 50 N (5 kg)
See more
- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx - Max. suspension load 50 N (5 kg)
Lamp box, outlet Ø 45 mm
Artikel-No. 9953
E-No 165920228
  • Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
  • Max. suspension load 50 N (5 kg)
See more
- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx - Max. suspension load 50 N (5 kg)
Lamp box, outlet Ø 48 mm
Artikel-No. 9954
E-No 165920328
  • Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
  • Max. suspension load 50 N (5 kg)
See more

Ceiling junction box

Ceiling junction box to accommodate electrical connections. With the optional light hook, the box is also ideally suited for installing and attaching luminaires. The wide range of ceiling boxes permits almost all conceivable installations.
  • Suitable for all types of formwork
  • Flat front part for fast, easy nailing
  • Integrated cap nut ensures secure fitting of an M5 light hook acc. to DIN EN 60670
  • The colour system ensures that the installation can be checked quickly

Processing instructions

Ceiling box 45° with light hook for fixing suspended luminaires.
Ceiling box 45° with light hook for fixing suspended luminaires.
Ceiling junction box with integrated M5 light hook acc. to DIN EN 60670.
Ceiling junction box with integrated M5 light hook acc. to DIN EN 60670.
You can very easily open slab ceiling boxes for filigree ceilings with the KAISER punch pliers.
You can very easily open slab ceiling boxes for filigree ceilings with the KAISER punch pliers.
The conduit is inserted tightly and accurately and the box is sealed with the cover.
The conduit is inserted tightly and accurately and the box is sealed with the cover.

Dimensions / Form

Product Ø:
96 mm
Product depth:
81 mm

Connections / Entries

Number of entries:
4
For conduit Ø:
20 mm, 25 mm

Assembly / Installation

Assembly type:
BB (solid construction)

Safety / Properties

Special application:
on-site mixed concrete
Certificate
