Ceiling junction box

- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
- Max. suspension load 50 N (5 kg)

Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
Max. suspension load 50 N (5 kg)

Read more Read less

Lamp box, outlet Ø 45 mm

Kaiser GmbH & Co.KG

Article No.: 9953

E-No: 165920228

EAN: 7611614025926

Product length: 84 mm

Product width: 84 mm

Product depth: 90 mm

Number of entries: 6

For conduit Ø: 20 mm, 25 mm

Shipping: 25

More product details

Datasheet (PDF)

accessories

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover

Article No. 11081

E-No 165950308

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover with cable entry

Article No. 11082

E-No 165950408

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover

Article No. 11088

E-No 165950608

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- Can also be used as cover for reserve conduit exits
- Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting)
- For Art.-No. 1245-60/-62/-63 and 1246-57

Screwed-on cover

Article No. 10100

E-No 165950008

Can also be used as cover for reserve conduit exits
Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting)
For Art.-No. 1245-60/-62/-63 and 1246-57

Cover 88x88 mm

Article No. 9919.10

E-No 374161008

UV-resistant

Cover

Article No. 11086

E-No 165950508

UV-resistant

- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
- Suspension load max. 5 kg

Insulated hook screw, 60 mm

Article No. 1225-60

E-No 163612060

For retrofitting in ceiling boxes (EN 60670)
With self-forming thread, insulated
Proof voltage: 2500 V tested
Suspension load max. 5 kg

- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested

Insulated round head screw, 3.5x50 mm

Article No. 9901.37.50

E-No 163013150

For retrofitting in ceiling boxes (EN 60670)
With self-forming thread, insulated
Proof voltage: 2500 V tested

Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab

Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab

Article No. 9959.68

E-No 165920008

similar

- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
- Max. suspension load 50 N (5 kg)

Lamp box, outlet Ø 45 mm

Article No. 9952

E-No 165920128

Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
Max. suspension load 50 N (5 kg)

- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
- Max. suspension load 50 N (5 kg)

Lamp box, outlet Ø 48 mm

Article No. 9954

E-No 165920328

Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
Max. suspension load 50 N (5 kg)

- Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
- Max. suspension load 50 N (5 kg)

Lamp box with perforated collar Ø 96 mm

Article No. 9954.10

E-No 165921028

Meets the product standard EN 60670-21 (suspension load) with our hook bolts 1225-xx
Max. suspension load 50 N (5 kg)

Product Information

Ceiling junction box

Ceiling junction box to accommodate electrical connections. With the optional light hook, the box is also ideally suited for installing and attaching luminaires. The wide range of ceiling boxes permits almost all conceivable installations.

Suitable for all types of formwork
Flat front part for fast, easy nailing
Integrated cap nut ensures secure fitting of an M5 light hook acc. to DIN EN 60670
The colour system ensures that the installation can be checked quickly

Processing instructions

Ceiling box 45° with light hook for fixing suspended luminaires.

Ceiling box 45° with light hook for fixing suspended luminaires.

Ceiling junction box with integrated M5 light hook acc. to DIN EN 60670.

Ceiling junction box with integrated M5 light hook acc. to DIN EN 60670.

You can very easily open slab ceiling boxes for filigree ceilings with the KAISER punch pliers.

You can very easily open slab ceiling boxes for filigree ceilings with the KAISER punch pliers.

The conduit is inserted tightly and accurately and the box is sealed with the cover.

The conduit is inserted tightly and accurately and the box is sealed with the cover.

Technical Data

Dimensions / Form

Product length:: 84 mm
Product width:: 84 mm
Product depth:: 90 mm

Connections / Entries

Number of entries:: 6
For conduit Ø:: 20 mm, 25 mm

Assembly / Installation

Assembly type:: BB (solid construction)

Safety / Properties

Special application:: on-site mixed concrete

Certificates

Certificate

2.9 MB | 14/11/2024

Accessories

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover

Article No. 11081

E-No 165950308

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover with cable entry

Article No. 11082

E-No 165950408

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- With central plug-in connector
- For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
- Screw not included

Cover

Article No. 11088

E-No 165950608

With central plug-in connector
For mounting wood screw Ø 3.5 mm, head Ø 6.5 - 7 mm, attach centrally in cover exit
Screw not included

- Can also be used as cover for reserve conduit exits
- Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting)
- For Art.-No. 1245-60/-62/-63 and 1246-57

Screwed-on cover

Article No. 10100

E-No 165950008

Can also be used as cover for reserve conduit exits
Attach the mounting ring (included) to the exit and place the end cover in position (bayonet fitting)
For Art.-No. 1245-60/-62/-63 and 1246-57

Cover 88x88 mm

Article No. 9919.10

E-No 374161008

UV-resistant

Cover

Article No. 11086

E-No 165950508

UV-resistant

- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested
- Suspension load max. 5 kg

Insulated hook screw, 60 mm

Article No. 1225-60

E-No 163612060

For retrofitting in ceiling boxes (EN 60670)
With self-forming thread, insulated
Proof voltage: 2500 V tested
Suspension load max. 5 kg

- For retrofitting in ceiling boxes (EN 60670)
- With self-forming thread, insulated
- Proof voltage: 2500 V tested

Insulated round head screw, 3.5x50 mm

Article No. 9901.37.50

E-No 163013150

For retrofitting in ceiling boxes (EN 60670)
With self-forming thread, insulated
Proof voltage: 2500 V tested

Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab

Adapter for bridging through insulation layer | can be installed above the formwork or below the finished ceiling slab

Article No. 9959.68

E-No 165920008
