Extra-large flush-mounted junction boxes
- For device screws Ø 3.5 mm - Max. tightening torque 0.8 Nm
- Compatible with Feller SNAPFIX® - Nail domes also serve as Prefix® connection points - Increased stability - Separately guided nailing points - With separator wall and stabilisation lid - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm
1 / 2
Open Cadenas Modal
- For device screws Ø 3.5 mm - Max. tightening torque 0.8 Nm
- Compatible with Feller SNAPFIX® - Nail domes also serve as Prefix® connection points - Increased stability - Separately guided nailing points - With separator wall and stabilisation lid - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm
  • For device screws Ø 3.5 mm
  • Max. tightening torque 0.8 Nm
Read more Read less

Wire-pull casing

AGRO AG
Artikel-No.: 9917
E-No: 155004908
EAN: 7611614261768
SZ
CE
Product length: 400 mm
Product width: 300 mm
Product depth: 120 mm
For conduit Ø: 20 mm, 25 mm, 32 mm, 40 mm, M50
Shipping: 10
More product details
Datasheet (PDF)

accessories

Extension pieces for extra-large flush-mounted junction boxes
Extension pieces for extra-large flush-mounted junction boxes
Artikel-No. 9917.68
E-No 155991908
See more
- smooth surface with rounded edge - UV-resistant
Screwed-on cover
Artikel-No. 9917.02
E-No 155912908
  • smooth surface with rounded edge
  • UV-resistant
See more
- Anodised aluminium - with full neoprene seal - Cover fixing with enclosed screws, non-rusting - Max. tightening torque 0.8 Nm
Waterproof cover
Artikel-No. 9917.03
E-No 155916908
  • Anodised aluminium
  • with full neoprene seal
  • Cover fixing with enclosed screws, non-rusting
  • Max. tightening torque 0.8 Nm
See more
- For installation on rebar, without support element, before front formwork placed against it
Plastering covers
Artikel-No. 9917.06
E-No 155913908
  • For installation on rebar, without support element, before front formwork placed against it
See more

similar

- For device screws Ø 3.5 mm - Max. tightening torque 0.8 Nm
Wire-pull casing
Artikel-No. 9916
E-No 155002908
  • For device screws Ø 3.5 mm
  • Max. tightening torque 0.8 Nm
See more
- For device screws Ø 3.5 mm - Max. tightening torque 0.8 Nm
Extra-large flush-mounted junction boxes
Artikel-No. 9916.21
E-No 155003908
  • For device screws Ø 3.5 mm
  • Max. tightening torque 0.8 Nm
See more
- For device screws Ø 3.5 mm - Max. tightening torque 0.8 Nm
Extra-large flush-mounted junction boxes
Artikel-No. 9917.21
E-No 155005908
  • For device screws Ø 3.5 mm
  • Max. tightening torque 0.8 Nm
See more

Extra-large flush-mounted junction boxes

The extra-large junction boxes are designed as a modular system: two alternative base units are available - one with a smaller and one with a greater depth - and the electrician can choose from a range of matching extension pieces (for extra depth), plastering covers, screwed-on covers, waterproof covers and universal covers.
  • Quick and secure installation using pre-inserted nails
  • Increased robustness
  • Conduit markings for drilling diameters
  • Stackable

Application examples

AGRO extra-large junction boxes create maximum space for pulling through and adding cables.
AGRO extra-large junction boxes create maximum space for pulling through and adding cables.
In the case of sub-ceiling insulation, the depth of the junction box can be increased using extension pieces.
In the case of sub-ceiling insulation, the depth of the junction box can be increased using extension pieces.
Also suitable for walls - fixed to the reinforcement using Prefix® installation technology.
Also suitable for walls - fixed to the reinforcement using Prefix® installation technology.

Application examples

AGRO extra-large junction boxes create maximum space for pulling through and adding cables.
AGRO extra-large junction boxes create maximum space for pulling through and adding cables.
In the case of sub-ceiling insulation, the depth of the junction box can be increased using extension pieces.
In the case of sub-ceiling insulation, the depth of the junction box can be increased using extension pieces.
Also suitable for walls - fixed to the reinforcement using Prefix® installation technology.
Also suitable for walls - fixed to the reinforcement using Prefix® installation technology.

Installation tips

Fixing in place on the ceiling formwork is done using eight pre-inserted nails. The nail channels have a predetermined breaking point, so that the nails will be removed together with the formwork.
Fixing in place on the ceiling formwork is done using eight pre-inserted nails. The nail channels have a predetermined breaking point, so that the nails will be removed together with the formwork.
The conduit entries can be easily opened using a step drill or a hammer and screwdriver.
The conduit entries can be easily opened using a step drill or a hammer and screwdriver.
If multiple different conduits are to be connected, the side walls can be removed using a hammer.
If multiple different conduits are to be connected, the side walls can be removed using a hammer.
Additional lugs facilitate secure fixing to the reinforcement bars using tying wire.
Additional lugs facilitate secure fixing to the reinforcement bars using tying wire.

Dimensions / Form

Product length:
400 mm
Product width:
300 mm
Product depth:
120 mm

Connections / Entries

For conduit Ø:
20 mm, 25 mm, 32 mm, 40 mm, M50

Assembly / Installation

Assembly type:
BB (solid construction)

Safety / Properties

Special application:
on-site mixed concrete
Certificate

9917

1.4 MB | 16/04/2024
Download
Flush-mounted juction housing.
Flyer

Flush-mounted juction housing.

The new generation - easy to process and flexible to combine. Leaflet available in German, French and Italian.

5.7 MB
Download
Extension pieces for extra-large flush-mounted junction boxes
Extension pieces for extra-large flush-mounted junction boxes
Artikel-No. 9917.68
E-No 155991908
See more
- smooth surface with rounded edge - UV-resistant
Screwed-on cover
Artikel-No. 9917.02
E-No 155912908
  • smooth surface with rounded edge
  • UV-resistant
See more
- Anodised aluminium - with full neoprene seal - Cover fixing with enclosed screws, non-rusting - Max. tightening torque 0.8 Nm
Waterproof cover
Artikel-No. 9917.03
E-No 155916908
  • Anodised aluminium
  • with full neoprene seal
  • Cover fixing with enclosed screws, non-rusting
  • Max. tightening torque 0.8 Nm
See more
- For installation on rebar, without support element, before front formwork placed against it
Plastering covers
Artikel-No. 9917.06
E-No 155913908
  • For installation on rebar, without support element, before front formwork placed against it
See more
