For facade and window systems
- Syntec® facade lead-through with push-in connection - Black
- Syntec® facade lead-through with push-in connection - Black
1 / 2
Open Cadenas Modal
- Syntec® facade lead-through with push-in connection - Black
- Syntec® facade lead-through with push-in connection - Black
  • Syntec® facade lead-through with push-in connection
  • Black
Read more Read less

Facade feed through pluggable synthetic

AGRO AG
Artikel-No.: 1545.99.08
E-No: 121670108
EAN: 7611614443447
Halogen-free
Min. clamping range: 3.5 mm
Max. clamping range: 8 mm
Installation opening (wall/ceiling) Ø: 27.5 mm
Spanner size: 27/24 mm
Drill hole Ø: 27.5 mm
Properties: halogen-free, black UV resistant (tested according to EN ISO 4892-2)
Protection class: IP66
Halogen-free: Yes
Shipping: 50
More product details
Datasheet (PDF)
Min. clamping range 3.5 mm 7 mm
Max. clamping range 8 mm 13 mm
Installation opening (wall/ceiling) Ø 27.5 mm 27.5 mm
Spanner size 27/24 mm 27/24 mm
Drill hole Ø 27.5 mm 27.5 mm
Properties halogen-free, black UV resistant (tested according to EN ISO 4892-2) halogen-free, black UV resistant (tested according to EN ISO 4892-2)
Protection class IP66 IP66
Halogen-free Yes
Artikel-No. 1545.99.08 1545.99.13
E-Number 121670108 121670208
Packaging / Shipping - / 50 - / 50
Show product chevron_right_FILL0_wght400_GRAD0_opsz24 chevron_right_FILL0_wght400_GRAD0_opsz24

Simple mounting

Guide the protective conduit (OD 20 - 21.2 mm) through the facade.
Guide the protective conduit (OD 20 - 21.2 mm) through the facade.
Click the conduit into the Syntec® facade feedthrough.
Click the conduit into the Syntec® facade feedthrough.
Click the Syntec® facade feedthrough into place in the facade.
Click the Syntec® facade feedthrough into place in the facade.
Sheet thickness 1 - 2 mm (2 sealing), Sheet thickness 2 - 4 mm (1 sealing)
Sheet thickness 1 - 2 mm (2 sealing), Sheet thickness 2 - 4 mm (1 sealing)
Quick and easy installtation from the outside.
Quick and easy installtation from the outside.
Pull the cable through and tighten the compression nut with a spanner.
Pull the cable through and tighten the compression nut with a spanner.
The innovative Syntec® facad feed- through is well able to withstand the effects of rain and wind.
The innovative Syntec® facad feed- through is well able to withstand the effects of rain and wind.
Free of thermal bridges and well sealed (IP66).
Free of thermal bridges and well sealed (IP66).

Dimensions / Form

Installation opening (wall/ceiling) Ø:
27.5 mm
Spanner size:
27/24 mm
Ø B:
27.0 mm
Drill hole Ø:
27.5 mm
Dimension H:
30 mm
Thread length L:
33 mm

Connections / Entries

Min. clamping range:
3.5 mm
Max. clamping range:
8 mm

Safety / Properties

Halogen-free:
Yes

Features

Properties:
halogen-free, black UV resistant (tested according to EN ISO 4892-2)

Approvals / Certifications

Protection class:
IP66

Storage / Installation / Operation

Minimum operating temperature:
-30 °C
Maximum operating temperature:
100 °C
