Fire protection cavity wall box
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
1 / 2
Open Cadenas Modal
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
  • Compatible with Feller SNAPFIX®
  • for F30-F90 or EI30-EI90 fire-protection walls
  • For timber stud walls F30-F90 or EI30-EI90
  • VKF Approval 26831
  • VKF Approval 26846
  • for plate thickness > 10 - 40 mm
  • matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10
  • For device screws Ø 3 mm
  • Max. tightening torque 0.5 Nm
  • Pipes must be sealed with sealing plugs on both sides of the pipes!
Read more Read less

Quickbox® Maxi HWD 90 2x2

AGRO AG
Artikel-No.: 9499-77.04
E-No: 372632709
EAN: 7611614276816
CE
S-Plus
Feller SNAPFIX compact
Product Ø: 83 mm
Product length: 145 mm
Product width: 145 mm
Product depth: 73.5 mm
Installation opening (wall/ceiling) Ø: 83 mm
Number of entries: 4
For conduit Ø: 25 mm
Drill/cut hole Ø: 83 mm
fire resistance class: EI 30, EI 90
Shipping: 5
More product details
Datasheet (PDF)

accessories

- for sealing electrical installation conduits - ECON® technology for easy cable entry - permanently flexible plastic
Sealing plug ECON® M20
Artikel-No. 1040-20
E-No 126573020
  • for sealing electrical installation conduits
  • ECON® technology for easy cable entry
  • permanently flexible plastic
See more
- for sealing electrical installation conduits - ECON® technology for easy cable entry - permanently flexible plastic
Sealing plug ECON® M25
Artikel-No. 1040-25
E-No 126573030
  • for sealing electrical installation conduits
  • ECON® technology for easy cable entry
  • permanently flexible plastic
See more

tools

Universal opening cutter for plastics
Universal opening cutter for plastics
Artikel-No. 1085-80
E-No 983228469
  • for manufacture of exact entry size
  • for low-voltage wiring of Ø 4 - 7.5 mm
  • for sheathed cabling up to 5 x 2.5 or 7 x 1.5
  • for cable NYY up to 5 x 2.5
  • for DIN EN conduits (flexible) with outer Ø of up to 20/25 mm
  • with 1/4" chuck size for battery-powered drills
See more

similar

- Compatible with Feller SNAPFIX® - for F30-F90 or EI30-EI90 fire-protection walls - For timber stud walls F30-F90 or EI30-EI90 - VKF Approval 26831 - VKF Approval 26846 - for plate thickness > 10 - 40 mm - matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10 - For device screws Ø 3 mm - Max. tightening torque 0.5 Nm - Pipes must be sealed with sealing plugs on both sides of the pipes!
Quickbox® Maxi HWD 90 3x2
Artikel-No. 9499-77.06
E-No 372632909
  • Compatible with Feller SNAPFIX®
  • for F30-F90 or EI30-EI90 fire-protection walls
  • For timber stud walls F30-F90 or EI30-EI90
  • VKF Approval 26831
  • VKF Approval 26846
  • for plate thickness > 10 - 40 mm
  • matching plug-in cover for Art. No. 9498-77 New Look one Art. No. 9919.10
  • For device screws Ø 3 mm
  • Max. tightening torque 0.5 Nm
  • Pipes must be sealed with sealing plugs on both sides of the pipes!
See more

Fire protection cavity wall box

HWD 90 cavity wall boxes for EI30-EI90 fire-protection walls ensure certified and fire-protection compliant electrical installation. Intelligent AFS technology reacts immediately to fire and heat and automatically seals the installation opening. This guarantees the fire resistance class of the fire-protection wall and secures escape routes. Use in all fire-protection walls and the fire-resistance duration of up to 90 minutes ensures maximum flexibility, even when the planning is changed. At the same time, it also maintains the wall's sound insulation requirements.
  • Compatible with Feller SNAPFIX®
  • For fire-protection walls F30-F90 or EI30-EI90
  • For timber stud walls F30-F90 or EI30-EI90
  • Maintains the wall's sound insulation protection
  • Retrofitting also possible
  • With fire-protection cover, can be used as a junction box
  • May not be used inside encapsulated walls

Processing note

Final assembly of certain flush-mounted devices for unplastered surfaces:
Due to the contact edge of the box, a small joint may form between the cover and the wall surface.
If the surface is not plastered, it is advisable to countersink the edge of the box holder into the wall to avoid any joints.

Montage Quickbox Maxi HWD 90 in Brandschutzwänden EI30 - EI90

Bore precise entry holes for the tubes.
Bore precise entry holes for the tubes.
Tubes must be sealed with sealing plugs.
Tubes must be sealed with sealing plugs.

Dimensions / Form

Product Ø:
83 mm
Product length:
145 mm
Product width:
145 mm
Product depth:
73.5 mm
Installation opening (wall/ceiling) Ø:
83 mm
Drill/cut hole Ø:
83 mm

Connections / Entries

Number of entries:
4
For conduit Ø:
25 mm

Assembly / Installation

Assembly type:
HW (drywall/lightweight construction)

Safety / Properties

Special application:
Fire protection

Approvals / Certifications

fire resistance class:
EI 30, EI 90
Instruction

Assembly instructions fire protection and sound insulation boxes.

Instructions available in German and French.

5.7 MB | 11/10/2022
Instruction

Fire-stop box Quickbox HWD90 Maxi.

Deep fire-stop box Quickbox HWD90 for electrical installations in fire-protection walls EI 30 - EI 90.

For installations with tubes.

596.8 KB | 04/10/2018
Download
Fire protection.
Brochure

Fire protection.

Box, housing and sealing systems for fire-protection walls and ceilings.

21.1 MB
