Attema’s Fiber Management Box (FM Box) with street cabinet is an above-ground distribution point (DP) that has been specially developed for at most 48 buried so-called Fiber-to-the-Home subscriber connection cables or ducts. For the splice mechanic the working method for sorting, splicing and storing the fiberglass cables is the same as for Attema’s well-known underground Fiber Mangement Plate(FMP). Thanks to the pre-assembled parts, the compact format, the supplied suspension bracket and the ease of assembly, the FM-Box is excellent suitable to use in the Attema street. The FM Box with street cabinet is also available with a Window Cut.
Street Cabinet + Hybrid FiberManagement Box
1 /
2
Mains distributor (NVt), 192 fibres, CSP, 16 outlets, loop, IP65
Product length:
250 mm
Product width:
500 mm
Product depth:
1170 mm
For conduit Ø:
10mm
Network level:
3
Splice cassette quantity:
16
Number of fibres (max.):
192
Protection class:
IP65
Halogen-free:
Yes
Street Cabinet + Hybrid FiberManagement Box
Dimensions / Form
- Product length:
- 250 mm
- Product width:
- 500 mm
- Product depth:
- 1170 mm
Connections / Entries
- For conduit Ø:
- 10mm
Safety / Properties
- Halogen-free:
- Yes
- Vibration resistance:
- Yes
- Chemical resistance:
- Yes
- Vibration/sharpness definition:
- Yes
Features
- Network level:
- 3
- Splice cassette quantity:
- 16
- Number of fibres (max.):
- 192
Certificates & Quality marks
- Protection class:
- IP65
Storage / Installation / Operation
- Minimum storage temperature:
- -10 °C
- Maximum storage temperature:
- 50 °C
- Minimum installation temperature:
- -10 °C
- Installation temperature max.:
- 50 °C
- Minimum operating temperature:
- -20 °C
- Maximum operating temperature:
- 60 °C
