Cost-effective roll-out of optic fiber networks With a smart and efficient approach, installing optic fiber networks in rural areas opens up tremendous opportunities. We developed the Midi Fiber Dome in consultation with industry experts. You can very easily connect 1 to 6 customers to this distribution point. Because of the flexible input ports, trendsetting contractors will retain their freedom when choosing a cable or tube system. This also presents many opportunities in terms of service and maintenance. The outcome will be the same; working more efficiently as opposed to working harder with reduced costs (TCO) as the final result.New DAC cables with 12, 24 or 48 fibres are simply buried directly into the ground. This means: lower costsand faster work. Flexibility in FttH conceptAttema offers the total solution for the roll-out of fiber networks. Depending on the spread of the homes,you choose the Midi Fiber Dome for a maximum of 6 connections, a distribution point for a maximumof 24 connections or a distribution point for a maximum of 48 connections. As installation is so easy,the FttH is also cost-effective outside urban areas.
Midi Fiber Dome
Midi fiber dome (MFD), 24 fibers, HS, 6 outlets, loop, IP68
Product length:
360 mm
Product width:
190 mm
Network level:
3
Splice cassette quantity:
2
Housing closure:
Twist lock
Protection class:
IP68
Halogen-free:
Yes
recommendations
Midi fiber dome (MFD), 24 fibers, CSP, 6 outlets, loop, IP68
Article number:
AT29293
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 3,0 mm – Ø 8,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors ANT or mini heatshrink.
- Scope of delivery: midi fibre dome, sealing material
Midi fibre dome (MFD), 24 fibers, HS, 4 outlets, loop, IP68
Article number:
AT29294
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 5,5 mm – Ø 10,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors heatshrink Ø 2.4 mm x 45 mm
Midi fibre dome (MFD), 24 fibers, CSP, 6 outlets, loop, IP68
Article number:
AT29295
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 5,5 mm – Ø 10,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors ANT or mini heatshrink.
Midi Fiber Dome
ETIM Product Classification:
Distributor for telecommunication
Distributor for telecommunication
Model:
Distributor enclosure
Mounting method:
With connecting lugs:
No
Max. number of dual cores:
Mounting dimension (standardised):
Other
110-compatible:
No
LSA:
No
SID:
Material:
Plastic
Degree of protection (IP):
IP68
Degree of protection (NEMA):
Colour:
Black
Height:
360 mm
Width:
190 mm
Depth:
Number of mountable connection strips:
DIN-compatible:
Compatible with Grade2TV according to XP-C 90-483:
Compatible with Grade3TV according to XP-C 90-483:
Dimensions / Form
- Product length:
- 360 mm
- Product width:
- 190 mm
Safety / Properties
- Halogen-free:
- Yes
- Vibration resistance:
- Yes
- Chemical resistance:
- Yes
- Vibration/sharpness definition:
- Yes
Features
- Network level:
- 3
- Splice cassette quantity:
- 2
- Housing closure:
- Twist lock
Certificates & Quality marks
- Protection class:
- IP68
Storage / Installation / Operation
- Minimum storage temperature:
- -10 °C
- Maximum storage temperature:
- 50 °C
- Minimum installation temperature:
- -10 °C
- Installation temperature max.:
- 50 °C
- Minimum operating temperature:
- -20 °C
- Maximum operating temperature:
- 60 °C
Midi fiber dome (MFD), 24 fibers, CSP, 6 outlets, loop, IP68
Article number:
AT29293
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 3,0 mm – Ø 8,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors ANT or mini heatshrink.
- Scope of delivery: midi fibre dome, sealing material
Midi fibre dome (MFD), 24 fibers, HS, 4 outlets, loop, IP68
Article number:
AT29294
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 5,5 mm – Ø 10,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors heatshrink Ø 2.4 mm x 45 mm
Midi fibre dome (MFD), 24 fibers, CSP, 6 outlets, loop, IP68
Article number:
AT29295
- Flexibility in FttH concept.
- Multi-functional product.
- Suitable for cable / duct diameters: Ø 5,5 mm – Ø 10,0 mm.
- Integrated strain relief per cable / duct.
- Window Cut possibility.
- Plug & Play installation.
- 2x 12 splice protectors ANT or mini heatshrink.
