Below-ground Fiber-to-the-Home networks are expanding at a steady rate. The European plans for the future are very ambitious. The more customer connection cables or ducts will be installed, the higher the risk that during the installation or afterwards failures due to excavation works will occur. In such event, it is of vital importance that the splice mechanic is able to repair the problem rapidly and in a compact manner. Next to repairing the closures can also be used for extending and/or connecting customer connection cables or ducts. This above-ground as well below-ground. Due to the universal character of the closures you will keep freedom of choice regarding the FttH concept.The clear sequence of actions enables the splice mechanic to execute his works rapidly and faultlessly using a compact closure. The IP68 waterproofness has been tested according to EN 60529.
Coupling-/repair closures
Repair sleeve CFD, mast 3.0 - 6.5 mm, CSP, HS, IP68
Product length:
155 mm
Product width:
85 mm
Network level:
3
Splice cassette quantity:
1
Number of fibres (max.):
2
Housing closure:
Twist lock
Protection class:
IP68
Halogen-free:
Yes
Packaging quantity:
25
Coupling-/repair closures
ETIM Product Classification:
Fibre optic distribution box
Fibre optic distribution box
Suitable for number of fibres:
2
Type of coupler:
Fusion splice
Material:
Plastic
Separated compartments:
No
Lockable:
No
Degree of protection (IP):
IP68
Degree of protection (NEMA):
Dimensions / Form
- Product length:
- 155 mm
- Product width:
- 85 mm
Safety / Properties
- Halogen-free:
- Yes
- Vibration resistance:
- Yes
- Chemical resistance:
- Yes
- Vibration/sharpness definition:
- Yes
Features
- Network level:
- 3
- Splice cassette quantity:
- 1
- Number of fibres (max.):
- 2
- Housing closure:
- Twist lock
Certificates & Quality marks
- Protection class:
- IP68
Storage / Installation / Operation
- Minimum storage temperature:
- -10 °C
- Maximum storage temperature:
- 50 °C
- Minimum installation temperature:
- -10 °C
- Installation temperature max.:
- 50 °C
- Minimum operating temperature:
- -20 °C
- Maximum operating temperature:
- 60 °C
