UHW50-BW / RD Hollow-Wall Juntion box, fire-resistant smoke-tight, Ø 16/19 mm
Installation opening (wall/ceiling) Ø:
76 mm
Number of entries:
2
For conduit Ø:
16 mm, 19 mm
Packaging quantity:
25
ETIM Product Classification:
Box/housing for built-in mounting in the wall/ceiling
Box/housing for built-in mounting in the wall/ceiling
Mounting method:
Hollow wall
Shape:
Round
Construction type:
Device connection box (round/square)
Model:
Single
Provided with revolving ring:
No
Couplable:
No
Equipped with:
Diameter:
76 mm
Length:
Width:
Depth:
Inner depth:
44 mm
Suitable for wall/board thickness:
Suitable for number of device inserts:
1
Mounting switching equipment:
Screwing
With screws:
No
Number of non-adjustable device fixing lugs:
Number of adjustable device fixing lugs:
Housing feed-through by break-out opening:
No
Housing feed-through by seal membrane:
No
Housing feed-through by nozzle:
No
Housing feed-through by step membrane:
No
Suitable for tube diameter:
16/19 mm
Suitable for cable diameter:
Pipe locking:
No
Pipe locking optional:
No
Inlet from the rear:
No
Number of inlets:
2
Number of included spouts:
0
Material:
Plastic
Halogen free:
No
Surface protection:
Untreated
Colour:
Red
Degree of protection (IP):
IP20
Degree of protection (NEMA):
Cover model:
None
Transparent cover:
No
Cover attachment:
Sealable:
No
Circuit integrity:
E60
With screening:
No
Airtight:
No
Max. conductor cross section:
6 mm²
Number of poles of the clamp:
0
Clamp position fixed:
No
Luminaire hook mounting:
No
Nozzle:
Double nozzle
Special application:
Fire protection
With partition panel:
Compliant with BS 4662:
Dimensions / Form
- Installation opening (wall/ceiling) Ø:
- 76 mm
Connections / Entries
- Number of entries:
- 2
- For conduit Ø:
- 16 mm, 19 mm
Installationdetails
- Assembly type:
- HW (drywall/lightweight construction)
