Attema’s Fiber Management Box (FM Box) is an above-ground distribution point (DP) that has been specially developed for at most 48 so-called Fiber-to-the-Home subscriber connection cables or ducts. For the splice mechanic the working method for sorting, splicing and storing the fiberglass cables is the same as for Attema’s well-known underground Fiber Mangement Plate(FMP). Thanks to the pre-assembled parts, the compact format, the supplied suspension bracket and the ease of assembly, the FM-Box is excellent suitable to use in the Attema street cabinet as well as in interior technical rooms. The FM Box is also available with a lock and a Window Cut.
Hybrid FiberManagement Box
Building distributor Gf-GV, 48 fibres, HS, 24 outlets, loop, IP65
Product length:
380 mm
Product width:
220 mm
Product depth:
130 mm
For conduit Ø:
20 mm, 25 mm
Network level:
4
Splice cassette quantity:
4
Number of fibres (max.):
48
Protection class:
IP65
Halogen-free:
Yes
Price (MSRP) / 1 ST:
€283.00
Price group:
720
Hybrid FiberManagement Box
Dimensions / Form
- Product length:
- 380 mm
- Product width:
- 220 mm
- Product depth:
- 130 mm
Connections / Entries
- For conduit Ø:
- 20 mm, 25 mm
Safety / Properties
- Halogen-free:
- Yes
Features
- Network level:
- 4
- Splice cassette quantity:
- 4
- Number of fibres (max.):
- 48
Approvals / Certifications
- Protection class:
- IP65
Storage / Installation / Operation
- Minimum storage temperature:
- -10 °C
- Maximum storage temperature:
- 60 °C
- Minimum installation temperature:
- -10 °C
- Installation temperature max.:
- 60 °C
- Minimum operating temperature:
- -20 °C
- Maximum operating temperature:
- 60 °C
