HWD 30 ceiling box for reliable fire protection from F30 to F90. In the event of a fire, the integrated fire-retardant coating intumesces immediately and seals the opening in the ceiling. The HWD 30 ceiling box also ensures safety during retrofitting.

The KAISER HWD 68+ fire protection boxes combine all the features of the HWD 68 and HWD 90. Furthermore, with their conduit entries, they cover all practical applications. Thanks to the tried-and-tested AFS technology, the HWD 68+ also guarantee a fire resistance duration of F30–F90 or EI30–EI90. The HWD 68+ also meets the fire resistance duration F30-B–F90-B in timber-frame and timber-panel construction, as well as in cross-laminated timber (CLT) construction. The HWD 68+ enables virtually unrestricted and universal electrical installation in fire protection walls.

Cable and conduit penetration systems for the fire-resistant sealing of penetrations and entries in fire protection walls. The certified seals are quick and easy to install and can even be fitted retrospectively over existing electric cables and conduits. They maintain the wall’s fire resistance class (EI30–EI90).

Box sealing system DS 90 / 74 mm for electric cables, cable bundles and conduits. The fire- and smokeproof box sealing system is quick and easy to install and can even be fitted over existing electric cables at a later stage. The product offers certified safety, ease of installation and ensures the wall’s fire resistance class (EI30–EI90).

KAISER ceiling seals DS 90 / 120 mm and DS 90 / 74 mm ensure that the ceiling’s fire resistance class of EI30–EI90 is safely maintained. To effectively prevent the spread of fire and smoke gas through feed-throughs for electric cables and electrical installation conduits in concrete or aerated concrete ceilings, these feed-throughs must be sealed in accordance with fire safety standards to the same fire resistance class as the ceiling. The DS 90 ceiling seal systems ensure this is achieved simply, quickly and safely.

The HWD 90 electronics box maintains the wall’s fire resistance class up to F120 or EI120 and F30-B / F60-B. It provides installation space for electronic switch devices, communication outlets, electric cables and terminals. The electronics box allows for the installation of both electric cables and installation conduits up to Ø 25 mm.

HWD 90 cavity wall boxes for EI30–EI120 fire protection walls ensure certified electrical installations that comply with fire safety regulations. The intelligent AFS technology reacts immediately to fire and heat and automatically seals the installation opening. The HWD 90 fire protection boxes are now also approved for use in timber walls constructed using timber frame or timber panel methods.

The PROTECT® solid timber one-gang junction box has been specially developed to meet the requirements of installation in solid timber elements. Thanks to its fixing with ribs and innovative wire entries, it ensures optimal, standardised installation in a solid timber element of visible-grade quality without the need for additional milling or extra effort. The innovative wire entries, thanks to their arrangement and design, allow for flexible cable routing and thus compensate for any installation tolerances that arise when performing cable routing within the solid timber element. Furthermore, the PROTECT® solid timber one-gang junction box maintains the fire resistance duration of the solid timber element from F30-B to F120-B without the need for additional encapsulation.

^{FlamoX® installation housings} for luminaires and loudspeakers protect lives and property in the event of a fire. Thanks to the integrated fire-retardant coating, the housings achieve the ceiling’s fire resistance class F30 (EI30) when luminaires and loudspeakers are installed in fire protection ceilings. They prevent the spread of fire and smoke gas, thereby safeguarding emergency routes within buildings.^FlamoX® fire protection housing offers certified safety.
