Installation solutions for external thermal insulation composite systems (ETICS)

Electrical installations suitable for all common types and thicknesses of insulation material.

Future-proof building technology combines architecture, functionality and energy efficiency. With forward-thinking planning, intelligent technology and suitable materials, energy savings can be achieved in line with the EU Buildings Directive and national regulations. KAISER products support compliance with the Building Energy Act (GEG) and enable thermal bridge-free, air-tight electrical installations – even with retrofitted internal insulation – whilst providing reliable protection against moisture damage.
Installation solutions in ETICS.
Brochure
Installation solutions in ETICS.

Electrical installation for all standard insulation material types.

16.5 MB
Energy efficiency.
Brochure
Energy efficiency.

Electrical installation for energy-saving buildings.

6.1 MB

Fundamentals and Installation

Fundamentals | Legislation and Technology.

Energy efficiency is becoming increasingly important in new builds and renovations. Since 2016, stricter requirements have been in force for insulation, heat protection and air tightness (EnEV, DIN 4108-7). The EU Directive on Energy Performance of Buildings has been implemented in Germany, Austria and Switzerland. The energy performance certificate assesses energy losses, is mandatory when selling or letting a property, and provides transparent information on consumption and efficiency, offering greater certainty and convenience when making property decisions.

Air-tight and thermal bridge-free electrical installations.

A heat-insulating, air-tight building shell in accordance with DIN 4108 protects the building structure from damp and mildew, as warm air does not condense on cool surfaces. In cavity or lightweight walls, moisture retardant foils or OSB panels act as the air-tight layer; in solid construction, this role is fulfilled by the interior plaster. Electrical installations must not damage these; electric cable and conduit entries must comply with DIN 60670-1. KAISER offers air-tight, thermal bridge-free solutions for cavity walls, Flush-mounting and internal insulation in accordance with DIN 18015-5.

Installation without heat bridges. Secure fixing of equipment in or to external wall insulation.

The quality of external wall insulation depends on the continuity of the insulation and the prevention of heat bridges. Extensions such as balconies or external installations such as sockets, luminaires, motion detectors or letterboxes pose risks of heat loss and building damage. KAISER offers secure, thermal bridge-free fixings for electrical appliances and components in ETICS, even as a retrofit. Thermography reveals weak spots. The thicker the insulation, the more serious the heat bridges.

Verification. Air tightness and absence of thermal bridges.

With rising energy prices, energy efficiency is becoming increasingly important for new builds and renovations. Since 2020, the Building Energy Act (GEG) has tightened the requirements for primary energy demand and, from 2024, will mandate the use of renewable energy in new heating systems. Thermal insulation and air tightness are key requirements. The energy performance certificate assesses energy losses and is mandatory when selling, letting or leasing a property. EU directives have been implemented in Germany, Austria and Switzerland.

Installation on masonry during the structural work phase

  • telescope switch box

    Secure mounting on walls and ceilings.
    The telescope switch box enables the safe installation of various accessories, such as outdoor lights, sockets and many other devices, in and on insulated façades.
    Optimised for today’s insulation thicknesses, the telescope switch box allows for flexible use in external façades with insulation thicknesses ranging from 80 to 200 mm. The one-gang boxes provide greater installation flexibility and can be easily connected for multiple combinations.

    • For insulation thicknesses from 80 to 200 mm
    • For the secure fixing of sockets and much more
    • For external insulation of walls and ceilings
    • With 2 screw domes
    • Standard combination distance: 71 mm
  • universal equipment carrier

    Secure fit without heat bridges.
    The universal equipment carrier enables the mounting of various accessories, such as outdoor lights and motion detectors, on an insulated façade. The fixing of the universal equipment carrier is done securely on the masonry, ensuring that the loads from the accessories can be supported permanently.
    The universal equipment carrier can be easily adapted to insulation thicknesses of up to 360 mm using extension elements. The large, universal screw-on surfaces can be plastered over and are designed for flexible equipment mounting.

    • Secure mechanical fixing to the masonry
    • Prevention of thermal bridges
    • Flexible adaptation to insulation thickness
    • Universal screw-on surface for fixing equipment
  • universal equipment carrier for combination inserts

    For future expansions without damaging the façade.
    The universal equipment carrier for combination inserts is designed for the installation of entry-phones and installation accessories in insulated façades. It provides the perfect base for intercom systems, sockets, switches and much more.
    The attachment is suitable for single, double or triple combinations and also allows for future expansions without damaging the façade. The equipment carrier with combination insert can be installed horizontally or vertically.

    • Guaranteed thermal bridge-free installation
    • For entry-phones and variable device installation combinations (1-gang to 3-gang)
    • For future expansions without damaging the façade
    • For insulation thicknesses up to 360 mm
  • system equipment carrier

    The system equipment carrier with multi-device insert is suitable for insulation thicknesses of 160–310 mm. Its modular design and the ability to assemble the individual elements in 10 mm increments allow for flexible adaptation to the insulation system.
    Quick and easy fixing using the screw-in wall plugs included in the scope of delivery ensures the device carrier is securely and permanently anchored to a wide range of substrates.
    The multi-unit insert allows for the installation of individual devices, but also enables the combination of devices in 2-unit or 3-unit configurations.

    • Quick and mechanically secure fixing to masonry
    • Modular adaptation to the insulation thickness
    • Combinations of up to three units possible
    • Two product variants enable a wide range of applications
  • ECON® Iso + one-gang junction box

    For wood fibre and rock wool
    The ECON® Iso + one-gang junction box is the solution for electrical installation in wood fibre insulation boards. Specially designed for use in rigid heat-insulating and render base boards, four swivels ensure secure anchoring – and it can even be retrofitted!
    The elastic sealing membrane of the ECON® technology guarantees air tightness and allows conduits or electric cables to be inserted toolless. This enables switches, sockets, intercoms and much more to be installed permanently, securely and without thermal bridges.

    • When installing in unplastered insulation boards – use mounting frames
    • Air-tight and thermal bridge-free electrical installation in accordance with DIN 18015-5
    • Suitable for pressure-resistant insulation boards with a thickness of 60 mm or more
    • 4 swivels for secure mechanical anchoring
    • Combinations can be created
  • ThermoX® Iso + installation housing

    For built-in LED luminaires and installation accessories in insulated ceilings.
    The installation housing for external insulation is the ideal solution for installing LED luminaires and installation accessories in external ceilings with external thermal insulation composite systems (ETICS). It provides a secure installation housing for LED luminaires with a power rating of up to 8 watts, as well as the ballast device. The installation housing is suitable for all common insulation materials, such as: wood fibre insulation, foam glass, mineral foam or expanded polystyrene (EPS).
    It enables the safe and thermal-bridge-free installation of fixed and swivelling LED built-in luminaires in insulated ceilings. The housing protects the surrounding insulation material from the high operating temperatures of the LED luminaire and also protects the LED luminaire itself from dirt.
    The integrated insulation element reliably prevents heat bridges. Insulation thicknesses ranging from 100 mm to 160 mm can be adjusted in 10 mm increments simply by trimming the housing. The installation depth for the LED luminaire or any other installation accessory ranges from 70 mm to 130 mm, depending on the set insulation thickness. For insulation thicknesses of 170 mm to 350 mm, the extension element is simply mounted behind the installation housing. The extension element is also adjustable in 10 mm increments.
    The front plate is available with a fixed installation diameter of 68 mm for hammering in, or with a universal mounting surface up to Ø 86 mm for a cutout.

All products for installation in the building shell on masonry at a glance.

Telescope equipment carrier
Artikel-No. 1159-60
  • for secure installation of luminaires and much more
  • for use with external insulation of walls and ceilings
  • installation area for dowel-free installation of accessories
Telescope switch box
Artikel-No. 1159-61
  • for secure fixing of sockets and much more
  • for use with external insulation of walls and ceilings
  • with 2 screw domes
  • Standardised combination distance 71 mm
Combination one-gang box
Artikel-No. 1159-62
  • for combinations with telescope switch box (Art. No. 1159-61)
One-gang junction box ECON® Iso +
Artikel-No. 1159-55
  • for retrofitting in ETICS with wood fibre and rock wool insulation boards
  • for insulation thicknesses of 60 mm and upwards
  • 4 swivelling cutters for secure mechanical fastening
  • 4 screw domes
  • Sealing lip on all sides
  • including centering aid
  • including setting tool (Art. No.1090-22) per packaging unit
Installation housing ThermoX® Iso +
Artikel-No. 1159-70
  • with external insulation of ceilings
  • for insulation thicknesses of 100 mm and above
  • Adjustment to the insulation thickness in 10 mm steps
  • for LED luminaires up to 8 Watt
  • max. luminaire installation depth 70 mm to 130 mm (insulation thickness less 30 mm)
  • Front panel with ceiling exit (CE) Ø 68 mm or universal up to Ø 86 mm
  • Space for ballast devices 120 mm x 30 mm x 28 mm (installation diameter 68 mm, installation depth 70 mm)
Extension element for ThermoX® Iso +
Artikel-No. 1159-71
  • for installation housing for external insulation
  • for insulation thicknesses 170 - 350 mm
  • Adjustment to the insulation thickness in 10 mm steps
Universal equipment carrier
Artikel-No. 1159-24
  • for use with externally-insulated walls
  • for secure fixing of lights, intercoms, motion detectors etc.
  • can be extended in steps of 100 mm each (max. 360 mm) using extension elements Art. No. 1159-27
  • can be reduced in 10 mm steps
  • With pre-cut rock wool parts through which the equipment carrier can be fed
Universal equipment carrier with combination insert
Artikel-No. 1159-26
  • for use with externally-insulated walls
  • For secure mounting of intercoms, switches, sockets and many more
  • Can be extended in steps of 100 mm using extension element
  • With pre-cut rock wool parts through which the equipment carrier can be fed
Extension element for universal equipment carrier
Artikel-No. 1159-27
  • to extend the Universal equipment carrier by 100 mm simply by latching on
  • can be reduced in 10 mm steps by cutting
  • with rock wool pre-cut parts to fill the extension panel
System equipment carrier 160 - 240 mm with universal mounting plate
Artikel-No. 9966.21
  • Adaptation to insulation thickness possible in 10 mm steps
  • Including 2 screw dowels
  • Insulation material: Neopor
  • Processing temperature: -5 °C / + 60 °C
ISO box set
Artikel-No. 1155-03
  • mounts on wall surface
  • for exterior insulation
  • consists of front part, extension ring and 2 ring attachment screws 40 mm
  • compensation height 70 mm, can be reduced by 3 x 5 mm to 55 mm
  • multiple extensions possible with extension ring
System equipment carrier 240 - 310 mm with multiple accessory insert for boxes
Artikel-No. 9966.32
  • Adaptation to insulation thickness possible in 10 mm steps
  • Including 2 screw dowels
  • Insulation material: Neopor
  • Processing temperature: -5 °C / + 60 °C
System equipment carrier 160-240 mm with multiple accessory insert for boxes
Artikel-No. 9966.31
  • Adaptation to insulation thickness possible in 10 mm steps
  • Including 2 screw dowels
  • Insulation material: Neopor
  • Processing temperature: -5 °C / + 60 °C
ISO extension ring
Artikel-No. 1155-02
  • compensation height 50 mm, can be reduced by 3 x 5 mm to 35 mm
  • Multiple extensions possible
  • 2 x 40 mm ring attachment screws needed, Art. No. 2472-40
System equipment carrier 240 - 310 mm with universal mounting plate
Artikel-No. 9966.22
  • Adaptation to insulation thickness possible in 10 mm steps
  • Including 2 screw dowels
  • Insulation material: Neopor
  • Processing temperature: -5 °C / + 60 °C

Installation in an existing ETICS (retrofitting)

  • mini equipment carrier

    Flush mounting without a heat bridge.
    The mini equipment carrier is ideal for the secure, flush-to-wall fixing of devices such as luminaires, cameras, motion detectors, letterboxes and many other systems that are to be fixed to already completed external thermal insulation composite systems (ETICS).
    The mini equipment carrier consists of two parts and is firmly anchored into the external thermal insulation composite system (ETICS) in just a few simple steps. It is suitable for medium-density wood fibre insulation boards, mineral foam boards, foam glass and insulation materials made from expanded polystyrene. The special screw-on surface allows for precise alignment – a major advantage over conventional fixings, particularly when multiple fixings are required.

    • For retrofitting in insulated façades
    • 4 swivels for secure anchoring
    • Precise, flush alignment of accessories
    • Guaranteed thermal bridge-free installation
    • No ingress of moisture
  • ECON® Iso + one-gang junction box

    For wood fibre and rock wool
    The ECON® Iso + one-gang junction box is the solution for electrical installations in wood fibre insulation boards. Specially designed for use in rigid heat-insulating and render base boards, four swivels ensure secure anchoring – and it can even be retrofitted!
    The elastic sealing membrane of the ECON® technology guarantees air tightness and allows conduits or electric cables to be inserted toolless. This enables switches, sockets, intercoms and much more to be installed permanently, securely and without thermal bridges.

    • When installing in unplastered insulation boards – use mounting frames
    • Air-tight and thermal bridge-free electrical installation in accordance with DIN 18015-5
    • Suitable for pressure-resistant insulation boards with a thickness of 60 mm or more
    • 4 swivels for secure mechanical anchoring
    • Combinations can be created
  • ECON® Styro55 one-gang junction box

    For retrofitting on insulated façades.
    The ECON® Styro55 one-gang junction box enables the retrofitting of installation accessories such as sockets and switches in composite thermal insulation systems (ETICS). Quickly, securely and without heat bridges. The box can be fitted and secured in just a few simple steps.

    The ECON® technology, featuring toolless and air-tight insertion, prevents cold draughts from reaching the masonry where electric cables are routed directly. Once pressed into the ETICS, the box is secured using the KAISER setting tool. The swivels cut firmly into the insulation material, providing the box with a permanently secure hold.

    • For retrofitting in insulated façades
    • Milling system prevents damage to cables
    • Guarantees thermal bridge-free installation
    • 4 swivels for secure anchoring
    • No ingress of moisture

All products for installation in a finished ETICS at a glance.

Mini equipment carrier with 4 swivels and 2 ribs
Artikel-No. 1159-50
  • Retrofitting in existing composite thermal insulation systems (ETICS)
  • consisting of anchor sleeve and attachment core
  • for insulation thicknesses of 80 mm and upwards
  • Screw-on surface with 10 mm tolerance compensation
  • 4 swivel cutters
  • 2 ribs
  • Sealing lip on all sides
  • Weight loading up to 30 N (3 kg)
  • equipment attached with self-tapping screws with Ø of 3.2 - 4 mm
One-gang junction box ECON® Iso +
Artikel-No. 1159-55
  • for retrofitting in ETICS with wood fibre and rock wool insulation boards
  • for insulation thicknesses of 60 mm and upwards
  • 4 swivelling cutters for secure mechanical fastening
  • 4 screw domes
  • Sealing lip on all sides
  • including centering aid
  • including setting tool (Art. No.1090-22) per packaging unit
One-gang junction box ECON® Styro 55
Artikel-No. 1555-51
  • Retrofitting in existing composite thermal insulation systems (ETICS)
  • for insulation thicknesses of 80 mm and upwards
  • 4 swivel cutters
  • Clamping ribs
  • Sealing lip on all sides
  • including setting tool (Art. No.1090-22) per packaging unit
ECON® Iso + / ECON® Styro 55 setting tool
Artikel-No. 1090-22
  • for fast and secure fixing of the ECON® Iso + (Art. No. 1159-55) and ECON® Styro55 (Art. No. 1555-51) one-gang junction box
Centering aid Ø 68 mm
Artikel-No. 1090-68
  • for precise installation openings in existing external composite thermal insulation systems (ETICS)
  • precise guidance of the SPECIAL cutter (Art. No. 1088-07)
  • can be combined for standard combinations of 71 mm
  • for exact positioning and easy fixing by nailing to the insulation board

Products for internal insulation

  • internal insulation box

    Installation in internal insulation systems.
    One-gang junction box for electrical installations in internal insulation systems. For the permanently secure and thermal-bridge-free fixing of switches, sockets and other devices in externally exposed walls with internal insulation. For an optimal indoor climate with proven protection against moisture damage.
    The internal insulation box is suitable for use in permeable insulation systems made from mineral or organic insulation materials with varying insulation thicknesses.
    The internal insulation box offers fitters a convenient solution for the professional installation of electrical systems in internal insulation systems. Its simple installation and flexible application options are particularly impressive. Once installed, it has been proven to contribute to the functionality of the insulation system.

    • Guaranteed thermal bridge-free installation
    • Moisture-regulating and insulating
    • Prevents moisture-related building damage
    • Suitable for use in many insulation systems
    • For insulation thicknesses from 30 to 100 mm
    • Installation on masonry without plaster

All products for installation in internal insulation at a glance.

Interior Insulation box for insulation thicknesses 30 - 100 mm
Artikel-No. 1159-90
  • One-gang junction box for insulated interior walls
  • including attachment adapter
  • rear cable entries
  • circumferential airtight sealing lip
  • Can be combined with each other
Fixing adapter for internal insulation box
Artikel-No. 1159-91
  • For secure fixing of the internal insulation box
  • For installation on masonry
  • For standard combinations 71 mm
Support connector
Artikel-No. 9060-88
  • For fully insulated through-wiring in combinations
  • For Art. Nos. 1159-90, 1555-51, 9069-03, 9069-04 and 9074-03
Signal cover Ø 60 mm
Artikel-No. 1181-60
  • Reusable
  • protects interior of box, screwing dome and screw heads when plastering

Contact a technical adviser

Do you have any questions about our products and services? We’re happy to help. Please enter your postcode below to find the right contact person for your enquiries. In addition to contacts from KAISER’s head office, your local contacts will also be displayed.

Please select the appropriate business area:

Please enter your city or zip code:
