- Scope of delivery: HTP with cover, LC/APC duplex coupling
House connection point (HÜP) as termination point for line technology (APL). Suitable for surface mounting. Consisting of base plate, splice cassette, housing cover and coupling bracket. Has a slot for microducts, single-pull seals and fibre optic customer cables. 1x input for microducts and 6x inputs for fibre optic customer cables. Equipped with 2x LC/APC duplex couplings, integrated shutter and dust caps. Coupling locking spring snaps in on the inside. Coupling can only be released by completely opening the housing cover. Cover cap to protect the plug connector. Slot for ANT crimp splice protection and mini heat-shrink tubing. Slot for up to 4x fibre optics and splices distributed across 1x splice cassette. Screw attachment for housing cover and base plate. Approved for funding projects by atene KOM .
Dimensions: 153 x 91 x 61 mm (LxWxH)
Weight: 200 g
Colour: White
Scope of delivery: House transfer point, coupling
Installation type: Surface-mounted
Protection class: IP20
Number of fibres: 4
Number of splice cassettes: 1
Number of couplings: 2
Coupling design: LC/APC DX shutter
atene KOM approved: Yes
Halogen-free: Yes
Loop length: 250 mm (splice cassette)
Bending radius: 30 mm (splice cassette)
Splice protection holder: ANT crimp / mini heat-shrink tubing
Number of cable/conduit entries: 6
Cable/conduit input Ø: 1x 10.0 mm, 1x 4.5 mm, 4x 4.0 mm
Storage temperature range -10 °C / +60 °C
Installation temperature range -10 °C / +60 °C
Operating temperature range -20 °C / +60 °C
