Installation housing ThermoX® Iso +

with external insulation of ceilings
for insulation thicknesses of 100 mm and above
Adjustment to the insulation thickness in 10 mm steps
for LED luminaires up to 8 Watt
max. luminaire installation depth 70 mm to 130 mm (insulation thickness less 30 mm)
Front panel with ceiling exit (CE) Ø 68 mm or universal up to Ø 86 mm
Space for ballast devices 120 mm x 30 mm x 28 mm (installation diameter 68 mm, installation depth 70 mm)

Installation housing for the thermal bridge-free installation of LED luminaires in insulated external ceilings, installation housing in accordance with DIN EN 60670/VDE 0606 made of plastic, with insulation, thermal bridge-free design in accordance with DIN 18015-5, for installation in insulated exterior walls.
For LED luminaires up to Ø 86 mm, up to 8 watts, ceiling exit 68 mm or variable up to 86 mm, dimensions LxWxH 220x110x160 mm, insulation thickness adjustable 100-160 mm, in 10 mm increments, protection class IP 20 according to DIN EN 60529, flame retardant according to DIN EN 60695 up to 650° C, halogen-free according to DIN VDE 0604-2-100, for the installation of LED built-in luminaires in insulated facades,
for 20 mm conduits and NYM cables (3 x 1.5 mm², 5 x 1.5 mm² or 3 x 2.5 mm², 5 x 2.5 mm² or 5 x 7.5 mm², low voltage)

Installation housing ThermoX® Iso +

Name: Installation housing ThermoX® Iso +
SKU: 1159-70
Price: 5410.0 EUR
Availability: InStock

Kaiser GmbH & Co.KG

Artikel-No.: 1159-70

EAN: 4013456547902

Product length: 220 mm

Product width: 110 mm

Product depth: 160 mm

For conduit Ø: 25 mm

Min. insulation thickness: 100 mm

Insulation thickness max.: 160 mm

Halogen-free: Yes

Power consumption in housing LED: 8 W

Shipping: 6

Price (MSRP) / 100 ST:

€5,410.00

Price group: 160

More product details

Datasheet (PDF)

accessories

- für Einbaugehäuse für die Außendämmung
- für Dämmstärken 170 - 350 mm
- Anpassung an die Dämmstärke in 10-mm-Schritten

Extension element for ThermoX® Iso +

Artikel-No. 1159-71

for installation housing for external insulation
for insulation thicknesses 170 - 350 mm
Adjustment to the insulation thickness in 10 mm steps

tools

Universal opening cutter for plastics

Artikel-No. 1085-80

for manufacture of exact entry size
for low-voltage wiring of Ø 4 - 7.5 mm
for sheathed cabling up to 5 x 2.5 or 7 x 1.5
for cable NYY up to 5 x 2.5
for DIN EN conduits (flexible) with outer Ø of up to 20/25 mm
with 1/4" chuck size for battery-powered drills

recommendations

- zur sicheren Befestigung von Leuchten und vielem mehr
- bei Außendämmung von Wänden und Decken
- Montagefläche zur dübellosen Geräteinstallation

Telescope equipment carrier

Artikel-No. 1159-60

for secure installation of luminaires and much more
for use with external insulation of walls and ceilings
installation area for dowel-free installation of accessories

- bei Außendämmung von Wänden
- zur sicheren Befestigung von Leuchten, Sprechanlagen, Bewegungsmeldern und vielem mehr
- erweiterbar durch Aufstockelemente Art.-Nr. 1159-27 um je 100 mm (max. 360 mm)
- reduzierbar in 10 mm-Schritten
- mit Steinwollzuschnitt zum Ausfüllen des Geräteträgers

Universal equipment carrier

Artikel-No. 1159-24

for use with externally-insulated walls
for secure fixing of lights, intercoms, motion detectors etc.
can be extended in steps of 100 mm each (max. 360 mm) using extension elements Art. No. 1159-27
can be reduced in 10 mm steps
With pre-cut rock wool parts through which the equipment carrier can be fed

- Anpassung an Dämmstärke in 10 mm Schritten möglich
- inklusive 2 Schraubdübel
- Isolationsmaterial: Neopor
- Verarbeitungstemperatur: -5 °C / + 60 °C

System equipment carrier 160 - 240 mm with universal mounting plate

Artikel-No. 9966.21

Adaptation to insulation thickness possible in 10 mm steps
Including 2 screw dowels
Insulation material: Neopor
Processing temperature: -5 °C / + 60 °C

Product Information

Installation housing ThermoX® Iso +

Installation housing for the secure and heat-bridge-free installation of rigid and swivelling built-in LED luminaires or other installation accessories in insulated ceilings. The housing protects the surrounding insulation material against the high operating temperatures of the LED luminaire and protects the LED luminaire itself against dirt. The integrated insulation element reliably prevents heat bridges.

For the installation of luminaires and installation accessories in insulated ceilings
Suitable for all standard insulation materials
Thermically-protected installation space
The integrated insulation element prevents heat bridges
For insulation thicknesses from 100 mm to 160 mm (170 mm to 350 mm with extension element)
Adjustment to the insulation thickness in 10 mm steps
Installation diameter up to ø 86 mm

Examples of use

Buildings are constructed heat-bridge-free using the ETICS composite thermal insulation systems, e.g. …

…insulated external ceilings of built-over terraces with lighting.

…insulated, recessed entrance areas with lighting.

…insulated facades with outdoor lighting over the entrance and garage door.

Heat-bridge calculation / temperature profile

A heat bridge calculation by the Passivhaus Institut, Darmstadt, shows that heat bridges can be reliably prevented by the installation housing for the external insulation. The installation housing is also suitable for use in passive houses.

Installation

Adapt installation housing to the measured insulation thickness.

Mark fixing point 55 mm from the luminaire centre point.

Alternative: Position the installation housing with the alignment markings for the luminaire and mark the drill hole.

Break out the conduit entry or cut an exact cable entry for air-tight installation, e.g. by using the KAISER universal opening cutter (Art.-No. 1085-80).

Screw installation housing to the ceiling and fit the screw covering.

Insert the conduit or cable into the installation housing; fit sealing plug to the conduit.

Ceiling exit ø 68 mm for knocking in, ceiling outlet up to ø 86 mm for cutting out.

Applying insulation and plaster. Fitting the LED installation spotlight with plenty of space for the ballast device.

Processing instructions

Universal front part for installation diameter of ø 68 mm for knocking in or universal up to ø 86 mm for cutting out (turn by 180°).

Installation depth 70 mm (insulation thickness 100 mm).

Installation depth 100 mm (insulation thickness 130 mm).

Installation depth 130 mm (insulation thickness 160 mm).

Technical Data

Dimensions / Form

Product length:: 220 mm
Product width:: 110 mm
Product depth:: 160 mm

Connections / Entries

For conduit Ø:: 25 mm

Assembly / Installation

Min. insulation thickness:: 100 mm
Insulation thickness max.:: 160 mm
Assembly type:: ETICS/external insulation

Safety / Properties

Halogen-free:: Yes
Power consumption in housing LED:: 8 W

Certificates

Certificate

Einbaugehäuse ThermoX® Iso + - Wärmebrückenberechnung
