Attema’s Fiber Management Box (FM Box) with street cabinet is an above-ground distribution point (DP) that has been specially developed for at most 48 buried so-called Fiber-to-the-Home subscriber connection cables or ducts. For the splice mechanic the working method for sorting, splicing and storing the fiberglass cables is the same as for Attema’s well-known underground Fiber Mangement Plate(FMP). Thanks to the pre-assembled parts, the compact format, the supplied suspension bracket and the ease of assembly, the FM-Box is excellent suitable to use in the Attema street. The FM Box with street cabinet is also available with a Window Cut.
Street Cabinet + Hybrid FiberManagement Box
1 /
3
Mains distributor NVt, 192 fibres, CSP, 48 outlets, loop, IP65
Product length:
250 mm
Product width:
500 mm
Product depth:
1170 mm
Network level:
3
Splice cassette quantity:
16
Number of fibres (max.):
192
Protection class:
IP65
Halogen-free:
Yes
Price (MSRP) / 1 ST:
€1,070.00
Price group:
710
Street Cabinet + Hybrid FiberManagement Box
Note
The construction of the net distributor is divided into two parts, one part of the distributor is buried in the ground and thus provides stability and support. The housing material used is a stainless steel with a 60 - 80 μm polyester powder coating. The overlength management of the cable or conduit systems of up to 6.30 m takes place in the main part of the distributor, the overlength is routed around the splice distributor box. Furthermore, fastening systems for the cable and conduit systems are pre-assembled. A device for universal locks (profile half-cylinder) is available. The distributor has a stainless mounting wall to mount all splice distributor boxes with cover (FMB) by the KAISER GROUP.
Dimensions / Form
- Product length:
- 250 mm
- Product width:
- 500 mm
- Product depth:
- 1170 mm
Safety / Properties
- Halogen-free:
- Yes
- Vibration resistance:
- Yes
- Chemical resistance:
- Yes
- Vibration/sharpness definition:
- Yes
Features
- Network level:
- 3
- Splice cassette quantity:
- 16
- Number of fibres (max.):
- 192
Approvals / Certifications
- Protection class:
- IP65
Storage / Installation / Operation
- Minimum storage temperature:
- -10 °C
- Maximum storage temperature:
- 50 °C
- Minimum installation temperature:
- -10 °C
- Installation temperature max.:
- 50 °C
- Minimum operating temperature:
- -20 °C
- Maximum operating temperature:
- 60 °C
