Multi Cable Entry MCE Pro EMC, NBR flat gasket

Milled aluminium, one-piece system

Powerful and safe clamping shield due to spring contact system
Low transfer impedance
Absolute process safety with regard to system assembly, full installation control with regard to screen
High tightness IP6X / IPX8 / IPX9K according to EN62444
Flexibility in the clamping area due to multiLAYER sealing units
High pull-out forces according to EN 62444
Extremely robust (impact resistance)
No auxiliary materials and lubricants necessary

Min. clamping range	10 mm	4 mm	6 mm
Max. clamping range	22.5 mm	10 mm	16 mm
Installation opening length	112 mm	112 mm	112 mm
Installation opening width	50 mm	50 mm	50 mm
Max. shield braiding	21 mm	12 mm	17 mm
Shield braid min.	7.5 mm	3.5 mm	4.5 mm
Cover for box/housing/casing Ø	112x50 mm	112x50 mm	112x50 mm
Protection class	IP68	IP68	IP68
Protection class with condition	IP68 (4 bar - 60 min)	IP68 (4 bar - 60 min)	IP68 (4 bar - 60 min)
Borehole distance X	130 mm	130 mm	130 mm
Borehole distance Y	32 mm	32 mm	32 mm
Article No.	1908.88.03.83.113	1908.88.08.83.111	1908.88.08.83.112
Pkg. inner / Pkg. outer	- / 1	- / 1	- / 1
