• Scope of delivery: OTO, 1x SC/APC DX coupler

Innovative fibre optic subscriber connection with a maximum installation depth of 32 mm for exact Flush-mounting in all standard one-gang junction boxes. The robust metal support ring with alignment markings allows for convenient installation with screw fastenings.
Perfect fibre storage management thanks to a rotatable and removable storage drum on the rear. Includes holder for up to 4 crimp splice connections.
Equipped with 1x SC/APC duplex coupling including shutter and dust cover.
Design compatible with all standard switch manufacturers thanks to standardised TAE cover.

Features Subscriber connection:
Network level 5
Installation type Flush-mounting
Protection class IP20
Impact resistance IK07
Number of fibres 1 - 4
Number of splice cassettes 1
Halogen-free Yes
Loop length (splice cassette) 150 mm
Bending radius (splice cassette) 25 mm
Splice protection holder CSS crimp / mini heat-shrink tubing
Number of cable entries 1
Storage temperature range -10 °C / +60 °C
Temperature range installation -10 °C / +60 °C
Temperature range in use -20 °C / +60 °C

Coupling properties:
Coupling | Type SC/APC duplex
Coupling | Type Without flange, SC duplex footprint
Coupling | Number 1
Coupling | Sleeve material Ceramic, slotted
Coupling | Housing material Plastic, halogen-free, flame-retardant
Coupling | Laser and dust protection Integrated protective flap, blind plug
Coupling | Insertion loss = 0.20 dB
Coupling | Mating cycles 1000
