Optical termination outlet (OTO), surface-mounted
Open Cadenas Modal
  • OTO

Compact fibre optic subscriber connection with a design height of 16 mm in signal white (RAL9003) glossy for surface mounting. Can be installed directly on the wall or with electrical screws on a flush-mounted device box. Suitable for cable entries from the bottom and from the rear with integrated strain relief. Suitable for providing a slot for accommodating a maximum of 2x LC/APC duplex or SC/APC simplex couplings, which can be inserted in two different height positions. Storage for crimp splice protection (CSS).
Features Subscriber connection:
Network level: 5
Dimensions: 85 x 85 x 16 mm (LxWxH)
Weight: 43 g
Colour: Signal white similar to RAL 9003
Installation type: Surface-mounted
Degree of protection: IP20
Halogen-free: Yes
Impact resistance: IK07
Loop length (splice cassette): 180 mm
Splice protection holder: CSS crimp / mini heat-shrink tubing
Number of fibre holders: 1 - 4
Bending radius: 25 mm
Cable entries: 3
Cable diameter: Ø 2.3 – 5.3 mm
Storage temperature range -10 °C / +60°C
Installation temperature range -10 °C / +60°C
Operating temperature range -20 °C / +60°C
Scope of delivery: Gf-TA subscriber connection, surface-mounted
Read more Read less

Optical termination outlet (OTO), unequipped

Unbekannt
Artikel-No.: 4252001
EAN: 4013456578432
Halogen-free
Product length: 85 mm
Product width: 85 mm
Product depth: 16 mm
Network level: 4
Splice cassette quantity: 1
Number of fibres (max.): 1
Protection class: IP20
Halogen-free: Yes
Shipping: 50
Price (MSRP) / 1 ST:
€9.20
Price group: 730
More product details
Datasheet (PDF)

Optical termination outlet (OTO), surface-mounted

The optical termination outlet will be the termination point of the optical fiber cable within the appartement / home. At this stage the connection to the optical network termination will be realized via an optical patch cable, as well as to the further individual network connections via WLAN/LAN for example.
  • Compact fibre-optic subscriber connection
  • unequipped, partial equipped and splice ready availabel
  • Overlength management
  • Suitable for CSP (Crimp-Splice protection)
  • Integrated strain relief

Montage

Create 5 mm drill holes.
Create 5 mm drill holes.
Optionally, attach it to the KAISER installation box using device screws.
Optionally, attach it to the KAISER installation box using device screws.
Fasten the fiber optic cable and engage the strain relief.
Fasten the fiber optic cable and engage the strain relief.
Optionally, fix the fiber optic cable with rear cable entry.
Optionally, fix the fiber optic cable with rear cable entry.
Insert the coupling in the desired position.
Insert the coupling in the desired position.
Insert, guide and put pigtails in place.
Insert, guide and put pigtails in place.
Lead fiber optic cable.
Lead fiber optic cable.
Perform splicing work and place the crimp splice protector in the holder.
Perform splicing work and place the crimp splice protector in the holder.
Snap the housing cover into place.
Snap the housing cover into place.

Dimensions / Form

Product length:
85 mm
Product width:
85 mm
Product depth:
16 mm

Safety / Properties

Halogen-free:
Yes

Features

Network level:
4
Splice cassette quantity:
1
Number of fibres (max.):
1

Approvals / Certifications

Protection class:
IP20

Storage / Installation / Operation

Minimum storage temperature:
-10 °C
Maximum storage temperature:
60 °C
Minimum installation temperature:
-10 °C
Installation temperature max.:
60 °C
Minimum operating temperature:
-20 °C
Maximum operating temperature:
60 °C
Instruction

Connectivity Optical termination outlet (OTO), LC/APC, surface-mounted

Assembly instructions

2.3 MB | 01/03/2022
Download
KAISER connectivity Network Level 4
Brochure

KAISER connectivity Network Level 4

Solutions for a professional fibre-to-the-home (FTTH) network.

22.9 MB
