Shaft sleeve holder for fibre management plate (FMP) incl. wall bracket

1 / 2

Scope of delivery: shaft sleeve holder, wall bracket

Shaft sleeve holder for fibre management plate (FMP) incl. wall bracket

Name: Shaft sleeve holder for fibre management plate (FMP) incl. wall bracket
SKU: 4232001
Price: 345.0 EUR
Availability: InStock

Attema B.V.

Artikel-No.: 4232001

EAN: 4013456582217

Product length: 665 mm

Product width: 325 mm

Product depth: 180 mm

Network level: 3

Protection class: IP68

Halogen-free: Yes

Price (MSRP) / 1 ST:

€345.00

Price group: 710

More product details

Datasheet (PDF)
